7 .1.1 Upper Side Cover (LU)
Tools
Phillips Screwdriver #2
Disassembly Procedures
9. Open the paper exit unit.
10. Remove the set screw BT4 8 of side cover (LU).
11. Pressing the exterior of the side cover (L), unlock
the interlock (three locations) with the side cover
(LU).
Assembly Procedures
1. Prepare a new side cover (LU).
2. Assemble the side cover (LU) according to the
reverse order of disassembling.
120 SuperScript 4400 — Maintenance Guide
Side Cover(LU)
Paper Exit Cover
Interlock
PUSH
Side Cover(L)
