Inserting/removal lateral carrier rails
You can insert/remove the later carrier rails when the box has been removed as
far as the stop » Fig. 91.
B
›
Insert the catches on the lateral carrier rail underneath the front edge of the
box in the direction of the arrow
1
›
Secure the other side of the lateral carrier rail in the hole
arrow.
Removal is carried out in the reverse order.
CAUTION
The maximum permissible load of the storage box is 2.5 kg.
■
Prevent objects stored in the storage box from slipping at all times using the
■
lateral carrier rails.
Before driving, the box must be pushed in so that it is not damaged.
■
Multifunction box (Octavia Estate)
Fig. 93 Multifunction box: pulling out/pushing in
88
Using the system
» Fig. 92.
the direction of the
2
Fig. 94
Removing the multifunction box

First read and observe the introductory information and safety warn-
ings on page 79.
The multifunction box under the roll-up luggage compartment cover is provided
for the storage of clothing and light objects with no sharp edges.
Pulling out
›
Fold down the front hooks on both sides of the luggage compart-
ment » page 82.
›
Grasp the rear bar » Fig. 93
A
the direction of the arrow
1
›
Place the rear bar onto the two hooks that are folded forward in the direction of
the arrow all the way to the stop.
2
Pushing in
›
Remove the rear bar from the hook in the direction of the arrow
›

Push in the complete multifunction box in the direction of the arrow
›
Place the rear bar against the front bar and press it on at both ends
›
Fold back the front hooks on both sides of the luggage compartment.
Removing/inserting
›
Remove the roll-up luggage compartment cover
›
Remove the multifunction box from the receptacle in the direction of the ar-
row » Fig. 94.
Insertion takes place in the reverse order.
›
When inserting, push the end of the bar marked   into the right receptacle and
the end of the bar marked   into the left receptacle. The arrows should be
pointing forward » Fig. 94.
CAUTION
The maximum permissible load of the multifunction box is 3 kg.

Variable loading floor in luggage compartment


Introduction
This chapter contains information on the following subjects:
Positions of the variable loading floor
Folding up variable loading floor
Dividing the luggage compartment
with both hands and pull out the complete box in
.
» page 85.
» Fig. 93.
3
.
4
.
B

89
90
90

