Vertical Movement

Name
LF
VT
ESC B
FF
ESC J
ESC j
ESC b
ESC Q
ESC /

Line Spacing

Name
ESC +
ESC 0
ESC 1
ESC 2
74
Section 4: Epson Emulation Mode Printer Commands
Dec Hex
10 0A
11 0B
27 66 0 n1 1B 42 0 n1,
n2...n16 0 n2...n16 00
12 0C
27 74 n 1B 4A n
27 106 n 1B 6A n
27 98 m 1B 62 m
n1...n8 0 n1...n8 00
27 81 n 1B 51 n
27 47 n 1B 2F n
Dec Hex
27 43 1B 2B
27 48 1B 30
27 49 1B 31
27 50 1B 32
Description
Line Feed
Advances the form one line.
Vertical Tab
Advances the paper to the next vertical tab stop.
Set Vertical Tab Stops
Sets up to 16 tab stops. The sequence ends with 0.
Form Feed
Advances the paper to the top of the next page.
Relative Move Base Line
Advances the paper by n/216 inches on 248x
printer; n/180 inches on 249x printer.
Reverse Relative Move Base Line
Feeds the paper by n/216 inches in the reverse
direction on 248x printer; n/180 inches in the
reverse direction on 249x printer.
Set Vertical Tabs in Channel
Sets vertical tab stops in specified channel by m.
m must be a one-byte decimal value from 0 to 7.
Set Right Margin
Sets the right margin in character positions at the
current pitch.
Select Vertical Tab Channel
Description
Set n/360 Line Spacing - 249x only
Set 1/8 Inch Line Spacing
Sets line spacing to eight lines per inch.
Set 7/72 Inch Line Spacing - 248x only
Sets line spacing to 7/72 lines per inch.
6 Lines Per Inch
Sets line spacing to six lines per inch.
