• data is the bit-mapped graphics information. The printhead moves at half
the speed of mode 2, giving better resolution.

Dual-Density Bit Image Graphics (Half Speed)

Use this command to print normal density bit images at 120 dpi horizontally
and 72 dpi vertically.
Format
Decimal
Hex
Usage Notes
• Ln and Hn identify the number of bytes in data.
To print less than 256 bytes:
— Hn is 0.
— Ln is the number of bytes you want to print.
To print more than 256 bytes:
— Divide the number of bytes you want to print by 256.
— The result is Hn.
— The remainder is Ln.
• data is the bit-mapped graphics information.
Mode
Hex
Dec Horizontal Density
8 08
9 09
11 0B
12 0C
13 0D
14 0E
16 10
ESC L Ln
27 76 Ln
1B 4C Ln
60
120
180
360
120
180
360
Hn data
Hn data
Hn data
Section 3: IBM Emulation Mode Printer Commands
Wires
24
24
24
24
24
24
48
51
