Lanier LP 036c Operating Instructions Manual page 64

IPP
A
Click [IPP].
The IPP setting dialog box appears.
B
To specify the IP address of the printer, type "http://printer's-ip-address/ printer" or
"ipp://printer's-ip-address/printer" in the [Printer URL] field.
(Example IP address is 192.168.15.16)
http://192.168.15.16/printer
ipp://192.168.15.16/printer
C
As necessary, type the names to distinguish the printer in [IPP Port Name]. Type a different
name from those of any existing port name.
If you omit this, the address typed in [Printer URL] will be set as the IPP port name.
D
If a proxy server and IPP user name are used, click [Detailed Settings], and then configure
the necessary settings.
Note
For more information about these settings, see SmartNetMonitor for Client Help.
E
Click [OK].
Standard TCP/IP Port
A Click [Add].
B Select [Standard TCP/IP], and then click [OK].
C Click [Next] in the "Add Standard TCP/IP Printer Port Wizard" window.
D Type the printer name or IP address in the "Printer Name or IP Address" box.
E Click [Finish] in the "Add Standard TCP/IP Printer Port Wizard" window.
