- Page 1 IFS MCR200-1T/1CX User Manual P/N 1076520 • REV A • ISS 07FEB12...
- Page 2 Copyright © 2012 UTC Fire & Security Company. All rights reserved. Trademarks and Interlogix, IFS MCR200-1T/1CX, the IFS Brand patents and logo are trademarks of UTC Fire & Security. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
- Page 3 European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact www.utcfireandsecurity.com information www.interlogix.com Customer support www.interlogix.com/customer-support...
-
Page 5: Table Of Contents
DC Power Jack 8 Installation 9 Installing the MCR200-1T/1CX 9 MCR200-1T/1CX LAN to LAN connection 9 Connecting the MCR200-1T/1CX 10 Chassis Installation and Rack Mounting 11 Power Information 13 Troubleshooting 14 FAQ 15 Specifications 17 Contacting Technical Support 19 IFS MCR200-1T/1CX User Manual... -
Page 7: Overview
The IFS MCR200-1T/1CX has a switching architecture with RJ-45 10/100Mbps Ethernet port and one asymmetric or symmetric Ethernet over VDSL port (Asymmetric refers to different upstream and downstream rates while symmetric refers to similar rates.) –... - Page 8 The following illustrations are typical application diagrams for the MCR200-1T/1CX. Note: A Slave device (CPE) must connect to a Master device (CO) through 50 or 75 ohm coaxial cable. It does not allow such connections from Master to Master or Slave to Slave. IFS MCR200-1T/1CX User Manual...
-
Page 9: Product Features
• Support up to 1536 bytes packet size, 802.1Q VLAN tag transparent • VDSL2 Stand-Alone transceiver for simple bridge modem application • Selectable Target Band Plan and Target SNR Margin • LED indicators for network diagnostics IFS MCR200-1T/1CX User Manual... -
Page 10: Hardware Description
LED indicators. Before connecting any network device, we recommend you read this chapter carefully. Front Panel The front panel of the MCR200-1T/1CX provides LEDs for interface monitoring as shown in Figure 1 and following table. Figure 1: MCR200-1T/1CX Front Panel IFS MCR200-1T/1CX User Manual... -
Page 11: Led Indicators
Indicates that the port link is Off. Indicates that the port is operating at 100Mbps. Green Indicates that the port is off or operating at 10Mbps. Rear Panel The units’ rear panel provides a simple interface for monitoring the MCR200-1T/1CX. IFS MCR200-1T/1CX User Manual... -
Page 12: Mode Dip Switch
CO setting should be selected for use at the IP camera location to allow for maximum bandwidth utilization of video streaming. CPE (Customer Premises Equipment) – the Slave device mode, usually the CPE device will be located at branch office, IFS MCR200-1T/1CX User Manual... -
Page 13: Fast And Interleave Mode
The default for the DIP switch settings is "ON" for all four switches, which sets the CPE mode. For selecting "CO" mode, please adjust the DIP 1 switch to "OFF". Please power off the MCR200-1T/1CX before making any transmission mode adjustments. IFS MCR200-1T/1CX User Manual... -
Page 14: Dc Power Jack
UPS (Uninterrupted Power Supply) is recommended to prevent data loss or network downtime. For additional protection against unregulated voltage or current surges, you may also want to consider surge suppression as part of your installation. IFS MCR200-1T/1CX User Manual... -
Page 15: Installation
Through a normal coaxial cable, the devices can be set up as a 100/65Mbps asymmetric backbone, but one MCR200- 1T/1CX must be selected as a Master (CO mode) and the other one as a Slave (CPE mode). Figure 3: MCR200-1T/1CX LAN to LAN connection IFS MCR200-1T/1CX User Manual... -
Page 16: Connecting The Mcr200-1T/1Cx
Connecting Multiple Ethernet Devices to an Ethernet LAN Refer to the following procedures to setup the MCR200- 1T/1CX to an Ethernet LAN. 1. Set the MCR200-1T/1CX to CO or CPE mode by using the DIP switch at the rear panel. IFS MCR200-1T/1CX User Manual... -
Page 17: Chassis Installation And Rack Mounting
1. Place your MCR200-1T/1CX on a hard flat surface, with the front panel facing you. 2. Carefully slide in the module until it is fully and firmly fitted into the slot of the MCR-R15 chassis. IFS MCR200-1T/1CX User Manual... - Page 18 MCR-R15 Chassis. Note: It is recommended to use the screws supplied with the mounting brackets. Otherwise, it may cause damage on the parts if wrong screws are used to install the rack. IFS MCR200-1T/1CX User Manual...
-
Page 19: Power Information
The MCR-R-15 DC outputs are a 2.5mm type that are designed to power the MCR family of media converters. Do not install any unit that is not supported by this rack, as this may cause damages on media converter and the rack backplane connectors. IFS MCR200-1T/1CX User Manual... -
Page 20: Troubleshooting
• Make sure that all cables are properly plugged in to the correct ports. • Make sure that the cable is not bad. • Make sure that the power adapters are functional for each device. IFS MCR200-1T/1CX User Manual... -
Page 21: Faq
The ratio is usually measured in decibels (dB). In digital communications, the SNR will probably cause a reduction in data speed because of frequent errors that require the source (transmitting) computer or terminal to resend some IFS MCR200-1T/1CX User Manual... - Page 22 (by designated frequency bands) for the transmission of upstream and downstream signals. The user has the ability to select a fixed band plan. Symmetric band plan provides better downstream performance while Asymmetric band plan provides better upstream performance. IFS MCR200-1T/1CX User Manual...
-
Page 23: Specifications
2 for RJ-45 10/100Base-TX port • 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft) Ethernet • 100Base-TX: 2-pair UTP Cat.5, 5e, 6 up to 100m (328ft) Cabling 50 ohm, RG58A/U, RG58C/U, RG58/U or 75 ohm, RG6 VDSL (Distance 3.0km) IFS MCR200-1T/1CX User Manual... - Page 24 IEEE 802.3x Full Duplex Pause frame Flow Control Standards ITU-T Compliance G.997.1 。 G.993.1 VDSL 。 G.993.2 VDSL2 (Profile 17a) 。 * The actual data rate will vary on the quality of the cable and environmental factors. IFS MCR200-1T/1CX User Manual...
-
Page 25: Contacting Technical Support
Contact technical support if you encounter any difficulties during this installation. Please make sure you have the requested diagnostic or log files ready before you contact us by phone or go to www.interlogix.com/customer-support. Technical Support Europe, Middle East and Africa Select Contact Us at www.utcfssecurityproducts.eu...
