- Page 1 IFS POE302-SP Ethernet Splitter User Manual P/N 1076527 • REV A • ISS 08FEB12...
- Page 2 Copyright © 2012 UTC Fire & Security Company. All rights reserved. Trademarks and Interlogix, IFS POE302-SP Ethernet Splitter, the patents IFS Brand and logo are trademarks of UTC Fire & Security. Other trade names used in this document may be...
- Page 3 European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact www.utcfireandsecurity.com information www.interlogix.com Customer support www.interlogix.com/customer-support...
-
Page 5: Table Of Contents
Hardware 2 Standard Compliance 2 Product Overview 3 LED Indicator 3 Hardware Installation 3 Before Installation 4 PoE Injector and Splitter Installation 4 Connecting with other 802.3at Devices 5 Specifications 7 Contacting Technical Support 8 IFS POE302-SP Ethernet Splitter User Manual... -
Page 7: Package Contents
Package Contents Thank you for purchasing the IFS POE302-SP Gigabit High Power over Ethernet (IEEE 802.3at) Splitter. Open the package containing the Ethernet Splitter and carefully unpack it. The box should contain the following items: ● IFS POE302-SP x1 ● User Manual x1 ●... -
Page 8: Hardware
PSE device per IEEE 802.3at is 30 watts. PD (Powered Device) is an Ethernet device powered by PoE supplied by the PSE such as IP cameras, access control panels, VoIP phones and Wireless access points (WAP), etc. IFS POE302-SP Ethernet Splitter User Manual... -
Page 9: Product Overview
10Mbps, 100Mbps and 1000Mbps. The unit adjusts automatically to the incoming data rate. The following section describes the hardware features of the POE302-SP. Carefully read this section before connecting any network device to this unit. IFS POE302-SP Ethernet Splitter User Manual... -
Page 10: Before Installation
IEEE 802.3at Power over Ethernet standard. 1. Connect a standard network cable from "Ethernet+DC" port of POE302-MS to "PoE In" port of POE302-SP. The POE LED of POE302-SP / POE302-MS will be constantly on. IFS POE302-SP Ethernet Splitter User Manual... -
Page 11: Connecting With Other 802.3At Devices
The POE302-SP also provide the alternative to make the non IEEE 802.3at devices the possibility to connect with an IEEE 802.3at in-line power device like Power over Ethernet Injector or Power over Ethernet Switch, the figure is as below. IFS POE302-SP Ethernet Splitter User Manual... - Page 12 Note: With IEEE 802.3at Power over Ethernet; the POE302- SP also can co-work with the IEEE 802.3at End-Span High Power over Ethernet Switch that is feeding power over pin 1, 2, and 3, 6. IFS POE302-SP Ethernet Splitter User Manual...
-
Page 13: Specifications
IEEE 802.3at High Power over Ethernet Standards Conformance Standards Compliance IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3at Power over Ethernet Regulation Compliance FCC Part 15 Class A, CE IFS POE302-SP Ethernet Splitter User Manual... -
Page 14: Contacting Technical Support
Technical Support Europe, Middle East and Africa Select Contact Us at www.utcfssecurityproducts.eu North America +1 855.286.8889 techsupport@interlogix.com Australia techsupport@interlogix.au IFS POE302-SP Ethernet Splitter User Manual...
