- Page 1 IFS MC250-4T/ Series User Manual P/N 1072574 • REV 00.05 • ISS 30JAN13...
- Page 2 Copyright © 2013 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and The IFS MC250-4T Series and logo are trademarks of United patents Technologies.
-
Page 3: Table Of Contents
Contents Overview 1 Package Contents 1 Product Features 2 Product Description 3 Front Panel 4 LED Indicators 5 Converter Top Panel 5 Wiring the Power Inputs 5 Wiring the Fault Alarm Contact 6 Mounting Installation 7 Installation Steps 11 Switch Operation 12 Troubleshooting 14 Specifications 15 Compatible SFP Modules 17... -
Page 5: Overview
Overview The Industrial Ethernet Media converter MC250-4T series, fully complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T and IEEE 802.3z 1000Base-SX / LX, the media conversion is quick and easy with simple Plug and Play installation. The MC250-4T series Industrial Ethernet Media converter also supports flow control and back pressure in half-duplex to eliminate packets loss. -
Page 6: Product Features
Product Features Physical Port Ports Fiber Optical Interface Model Name Copper Optical Mode Distance 1 x 100Base-FX MC250-4T/1FM Mutil-mode MC250-4T/1FS Single- 15km mode MC250-4T/2S Multi / Single 10/100Base- Mode Depends on SFP Module 2 x 100Base-FX Layer 2 Features • Complies with IEEE 802.3, IEEE 802.3u 10/100Base-TX, 100Base-FX •... -
Page 7: Product Description
Industrial Case / Installation • IP-30 Metal case / Protection • DIN Rail and Wall Mount Design • 12 to 48V DC, redundant power with polarity reverse protect function and removable connector terminal block for master and slave power • -40 to 75 Degree C operating temperature range Product Description The MC250-4T series are 4-Port 10/100Mbps + 1 or 2 100FX... -
Page 8: Front Panel
Front Panel The figure below shows the MC250-4T/1FM-1FS and the MC250-4T/2S. IFS MC250-4T/XXX Series User Manual... -
Page 9: Led Indicators
LED Indicators Color Function Green Lit: indicates that power 1 has power. Green Lit: indicates that power 2 has power. Green FAULT Lit: indicates that either power 1 or power 2 has no power. Green Lit: indicates that the Fiber port is successfully Fiber Optical connected to the network at 100Mbps. -
Page 10: Wiring The Fault Alarm Contact
1. Insert positive / negative DC power wires into the contacts 1 and 2 for POWER 1, or 5 and 6 for POWER 2. V1- V1+ V2- V2+ 2. Tighten the wire-clamp screws to prevent the wires from disconnecting. Power 1 Fault Power 2 Wiring the Fault Alarm Contact... -
Page 11: Mounting Installation
Insert the wires into the fault alarm contacts Note: The wire gauge for the terminal block should be in the range between 12 ~ 24 AWG. The alarm relay circuit accepts up to 30V, max. 3A currents. Mounting Installation This section describes how to mount the MC250-4T and make connections to it. - Page 12 Mounting to a DIN-Rail The DIN-Rail kit comes assembled on the MC250-4T out of the box. Please refer to following figures to hang the MC250- 4T on a DIN-Rail. 1. Lightly press down and push the bottom of the DIN-Rail connector mount into the track.
- Page 13 2. Check that the DIN-Rail connector mount is tightly mounted on the track. 3. Please refer to following procedures to remove the MC250- 4T from the track. 4. Lightly press down and pull the bottom of DIN-Rail connector mount to remove it from the track. Mounting to a Wall To install the MC250-4T on the wall, please follows the instructions described below.
- Page 14 2. Place the wall mount plate on the rear panel of the MC250- 3. Assemble the wall mount plate on the MC250-4T. 4. Use the hook holes at the corners of the wall mount plate to hang the MC250-4T on the wall. IFS MC250-4T/XXX Series User Manual...
-
Page 15: Installation Steps
Installation Steps Step 1: Unpack the Industrial Fast Ethernet Switch. Step 2: Check the DIN-Rail is screwed on the Industrial Fast Ethernet Switch. (Please refer to DIN-Rail Mounting section for DIN-Rail installation. If you want to wall mount the Industrial Fast Ethernet Switch, then please refer to Wall Mount Plate Mounting section for wall mount plate installation. -
Page 16: Switch Operation
Switch Operation Address Table The Industrial Fast Ethernet Switch is implemented with an address table. This address table is composed of many entries. Each entry is used to store the address information of a node in the network, including MAC address, Port No., and etc. - Page 17 from the frames before transmission. No error packets occurrence, it is the best choice when a network needs efficiency and stability. The Industrial Fast Ethernet Switch scans the destination address from the packet-header, searches the routing table provided for the incoming port and forwards the packet, only if required.
-
Page 18: Troubleshooting
Troubleshooting This chapter contains information to help you solve issues. If the Industrial Fast Ethernet Switch is not functioning properly, make sure the Industrial Fast Ethernet Switch was set up according to instructions in this manual. The Link LED is not lit Solution: Check the cable connection of the Industrial Fast Ethernet Switch. -
Page 19: Specifications
Specifications Model MC250-4T/1FM MC250-4T/1FS Hardware Specification Ports 4 x 10/100Base-TX, Auto-negotiation, Auto-MDI/MDI-X 10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters, Copper max.) Cable 100Base-TX : 2-pair UTP Cat. 5, 5e, 6 cable (100meters, max.) Port 1 x 100Base-FX 50/125μm fiber Cable 9/125μm fiber... - Page 20 Operating: -40~75 Degree C Temperature Storage: -40~85 Degree C Operating: 5% to 90%, Storage: 5% to 90% (Non- Humidity Operating condensing) Regulation Compliance FCC Part 15 Class A, CE Model M250-4T/2S Hardware Specification Ports 4 x 10/100Base-TX, Auto-negotiation, Auto-MDI/MDI-X 10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters, Copper max.) Cable...
-
Page 21: Compatible Sfp Modules
IEEE 802.3 Ethernet, 10Base-T Standards Compliance IEEE 802.3u Fast Ethernet, 100Base-TX, 100Base-FX IEEE 802.3x Full-duplex Flow control IEC60068-2-32(Free Fall) Stability testing IEC60068-2-27(Shock) IEC60068-2-6(Vibration) Operating: -40~75 Degree C Temperature Storage: -40~85 Degree C Operating: 5% to 90%, Storage: 5% to 90% (Non- Humidity Operating condensing) Regulation Compliance... - Page 22 RJ45 Cable Drawing The following figure shows the pin allocation and color of a straight cable, and connection of a crossover cable. Please make sure your connected cables are with same pin assignment and color as above picture before deploying the cables into your network.
-
Page 23: Contacting Technical Support
Contact technical support if you encounter any difficulties during this installation. Please make sure you have the requested diagnostic or log files ready before you contact us by phone or go to www.interlogix.com/customer-support. Technical Support Europe, Middle East and Africa Select Contact Us at www.utcfssecurityproducts.eu...
