SLM-7650 Satellite Modem
Operation
Menu Item
M&C FIRMWARE
BOOT FIRMWARE
BULK FIRMWARE
DISPLAY BRIGHTNESS
EXT AGC: MIN PWR
EXT AGC: MAX PWR
USB REFLASH
MASTER RESET
Displays the M&C module firmware version. The display includes the month, day,
and year.
Displays the BOOT module firmware version. The display includes the month, day,
and year.
Displays the BULK module firmware version. The display includes the month, day,
and year.
Sets the brightness setting of the front panel menu.
Press [ENTER] to begin. Press [
the flashing cursor, from 25 to 100%. Press [ENTER] to execute the change.
Sets the AGC voltage for receive signal level of -60.0 dBm.
Sets the AGC voltage for receive signal level of -15.0 dBm
Configures the modem for upgrade via the USB connector on the front panel.
Master reset function.
CAUTION
Initiating a hard reset will reset the modem and set the default configuration
settings. Initiating a soft reset will reset the modem hardware, but saves the
current configuration settings.
Select [ENTER] once to access HARD or SOFT. Press [
selection. Press [ENTER]. Select Yes or No, and press [ENTER] again.
Note:
The following system settings will not revert to the default values upon a
hard reset:
Remote Format
Remote Address
Remote Baud Rate
3-32
Specifications/usage
↑
] or [
↓
] to increment or decrement the number at
Revision 4
MN/SLM7650.IOM
←
] or [
→
] to make the
