SLM-7650 Satellite Modem
Remote Control Specifications
Bulk Consol.
Status
(continued)
Parameter
Number
107
108
109
110
111
112
113
114
(Note 5)
115
(Note 6)
116
(Note 6)
117
(Note 9)
118
Notes:
1. Data will only be returned if TX Overhead is programmed for ASYNC. Comma is always returned.
2. Data will only be returned if RX Overhead is programmed for ASYNC. Comma is always returned.
3. Data will only be returned if the option card is installed and the TX Overhead is programmed for DI. Comma is always
returned.
4. Data will only be returned if the option card is installed and the RX Overhead is programmed for DI. Comma is always
returned.
5. Data will only be returned if the option card is installed and the TX Overhead is programmed for IDR. Comma is always
returned.
6. Data will only be returned if the option card is installed and the RX Overhead is programmed for IDR. Comma is always
returned.
7. Data will only be returned if the option card is installed. Comma is always returned.
8. Data will only be returned if the option card is installed and either TX or RX Overhead is programmed for ASYNC. Comma is
always returned.
9. Data will only be returned if the option card is installed and TX or RX Overhead is programmed for DI. Comma is always
returned.
Parameter Name
(Command Reference)
Receive IESS-310 Mode
(ref. 'R310_' command).
Transmit BPSK Data Ordering
(ref. 'TDA_' command).
Receive BPSK Data Ordering
(ref. 'RDA_' command).
RTS TX-IF Control Mode
(ref. 'RTSM_' command).
Scrambler Type
(ref. 'SCRT_' command).
Descrambler Type
(ref. 'DCRT_' command).
Modulator RS Codeword
(ref. 'MRSC_' command).
Demodulator RS Codeword
(ref. 'DRSC_' command).
IDR TX ESC Type
(ref. 'TET_' command).
IDR RX ESC Type
(ref. 'RET_' command).
Terrestrial ASYNC Source
(ref. 'TAS_' command).
DDO/IDI Loopback
(ref. 'DIL_' command).
Description
p107 = n, where 'n' is '0' (off) or '1' (on).
p108 = n, where 'n' is '0' (NRM), '1' (INV).
p109 = n, where 'n' is '0' (NRM),'1' (INV).
p110 = n, where 'n' is '0' (off) or '1' (on).
p111 = n, where 'n' is '0' (IESS), '1' (OM73), or '2' (TURBO).
p112 = n, where 'n' is '0' (IESS), '1' (OM73), or '2' (TURBO).
p113 = n, where 'n' is '0' RS(225,205,10) depth 8, '1'
RS(225,205,10) depth 4, '2' RS(219,201,9) depth 8,
'3' RS(219,201,9) depth 4, '4' RS(194,178,8) depth
4, or '5' RS(126,112,7) depth 4.
p114 = n, where 'n' is '0' RS(225,205,10) depth 8, '1'
RS(225,205,10) depth 4, '2' RS(219,201,9) depth 8,
'3' RS(219,201,9) depth 4, '4' RS(194,178,8) depth
4, or '5' RS(126,112,7) depth 4.
p115 = n, where 'n' is '0' (2x32Kbits/s Audio) or '1' (64Kbit/s
Data).
p116 = n, where 'n' is '0' (2x32Kbits/s Audio) or '1' (64Kbit/s
Data).
p117 = n, where 'n' is '0' (J2) or '1' (J6).
p118 = n, where 'n' is '0' (OFF) or '1' (ON).
A–43
Revision 4
MN/SLM7650.IOM
