SLM-7650 Satellite Modem
Remote Control Specifications
Remote
Notes:
Modem AUPC
1. Always wait 3 seconds between consecutive remote modem command/status polls.
Commands
2. If Local AUPC is not enabled, status commands will return last known condition. They will also request status from the
remote modem. This allows a second request to return proper status.
Remote AUPC
Command:
Enable
Response:
Remote
Command:
Interface
Response:
Substitution
Pattern
Status:
Response:
Remote
Command:
Interface
Response:
Baseband
Loopback
Status:
Response:
Remote
Command:
Interface Read
Response:
Error Status
Example:
Command:
Response:
<add/RPC_xxx'cr'
>add/RPC_xxx'cr''lf']
<add/RISP_xxx'cr'
>add/RISP_xxx'cr''lf']
<add/RISP_'cr'
>add/RISP_xxx'cr''lf']
<add/RBBL_xxx'cr'
>add/RBBL_xxx'cr''lf']
<add/RBBL_'cr'
>add/RBBL_xxx'cr''lf']
<add/RRES_'cr'
>add/RRES_nE-e'cr''lf']
<add/RRES_'cr'
>add/RRES_2E-6'cr''lf']
A–22
Where: xxx = ON or OFF (remote AUPC enable).
Note: ASYNC Overhead only.
Where: xxx = ON or OFF (remote transmit 2047 pattern
enable).
Note: Transmit 2047 Pattern.
Where: xxx = ON or OFF (remote baseband loopback enable).
Note: ASYNC Overhead only.
Where:
n = 1 to 9 (error rate number).
e = 2 to 6 (exponent).
Note: Received 2047 Pattern.
This command returns 2047 BER from the remote AUPC
modem. If data is not valid, the message 'No_Data' is returned
in lieu of BER data.
Revision 4
MN/SLM7650.IOM
