SLM-7650 Satellite Modem
Remote Control Specifications
Change
Command:
Status
Response:
<add/CS_'cr'
>add/CS_x'cr''lf']
Bit 6 = 1 always.
Bit 5 = TX backward alarm 1.
Bit 4 = TX backward alarm 2.
Bit 3 through Bit 0 = Binary representation (0 to 10) of
the number of backward alarm stored faults.
Character 'q': Interface Backward Alarm status character 2.
Bit 6 = 1 always.
Bit 5 = TX backward alarm 3.
Bit 4 = TX backward alarm 4.
Bit 3 = RX backward alarm 1.
Bit 2 = RX backward alarm 2.
Bit 1 = RX backward alarm 3.
Bit 0 = RX backward alarm 4.
Where:
The 'x' character is defined as follows:
'@' = no change since last BCS_ and BCSF_ polls.
'A' = BCS_ response has changed since last BCS_ poll.
'B' = BCSF_ response has changed since last BCSF_
poll.
'C' = Both responses have changed since last BCS_ and
BCSF_ polls.
This command indicates that a change has or has not
occurred on either the BCS_ or the BCSF_ response since
the last BCS_ or BCSF_ poll.
A–46
Revision 4
MN/SLM7650.IOM
