SLM-7650 Satellite Modem
Operation
Menu Item
DROP CHANNEL
ASSIGNMENTS
INSERT CHANNEL
ASSIGNMENTS
DDO/INI LOOP
Drop Channel Assignments: Maps terrestrial time slots to transmit satellite channels.
Terrestrial time slots:
T1 = 1 to 24
E1 (CCS) = 1 to 31
E1 (CAS) = 1 to 15 and 17 to 31
Channels: 1 to N (N = Satellite Data Rate ÷ 64 kbps)
N = 30 (1920.0 kbps) is a transparent mode which
disables time slot to channel mapping.
On entry, drop channel 1 and the current time slot are displayed. Press [↑] or [↓] to
select the drop channel to be programmed.
Press [ENTER] to begin programming. Press [↑] or [↓] to select the time slot for each
available drop channel by incrementing or decrementing the digit at the flashing cursor.
Press [ENTER] to execute the change.
Note: This menu is only available for the D&I option.
Insert Channel Assignments: Maps received satellite channels to terrestrial time slots.
Terrestrial time slots:
T1 = 1 to 24
E1 (CCS) = 1 to 31
E1 (CAS) = 1 to 15 and 17 to 31
Channels: 1 to N (N = Satellite Data Rate ÷ 64 kbps)
N = 30 (1920.0 kbps) is a transparent mode which
disables time slot to channel mapping.
On entry, satellite channel 1 and the current terrestrial time slot are displayed. Press [↑]
or [↓] to select the satellite channel to be programmed. Press [ENTER] to choose the
satellite channel to be programmed. Press [↑] or [↓] to select the terrestrial time slot for
each available satellite channel by incrementing or decrementing the digit at the flashing
cursor. If a time slot is unused, select NI (Not Inserted). Press [ENTER] to execute the
change.
Note: This menu is only available for the D&I option.
Selects Drop Data Output to Insert Data Input Loop. This provides an internal path so an
external cable connection does not have to be connected. Selection is ON or OFF.
Note: This menu is only available for the D&I option.
3-16
Specifications/usage
Revision 4
MN/SLM7650.IOM
