Connecting the Power Cable

Connecting to the Host Computer

1
Confirm that the power switch on the rear of the AIT library is turned off
(a is pressed).
2
Connect one end of the power cable to the power supply connector and the
other end to the electric outlet.
Connect the AIT library and the host computer with a SCSI cable. This section
explains general connecting steps. To connect, use the Ultra Wide SCSI cable
sold at stores. The library side uses the 68-pin half pitch connector.
When connecting other SCSI devices together with the AIT Library, see
"Connecting SCSI Peripheral Devices" (page 20).
Caution
• Do not connect the AIT library to the High Voltage Differential (HVD) SCSI
bus. If connected, the library or other devices on the SCSI bus may be
damaged.
• When connecting the Wide SCSI cable, turn off all of the connecting devices,
including the host computer.
• When connecting the AIT library as the last device on the SCSI bus, be sure
to attach the provided terminator. Also, if the host computer is equipped with
a single-end SCSI host adapter, use a terminator that supports single-end.
When the wrong terminator is used, the device may be damaged.
• In Ultra Wide SCSI, make the length of the LVD (Low Voltage Differential)
SCSI cable, which connects the host computer and the device at the end of the
