N o t e s o n
C r e a t i n g
D o w n l i n k C l i e n t
Ports
where
<slot-id> is the slot letter where the module is installed.
<port list> is the switch port(s) to be used as downlink client ports.
For example:
ProCurve (config)# access-controller b client-ports a2,a6
assigns two downlink client ports and two new client VLANs (see Figure 12­
5). BDP, the downlink port for the module in slot B, is a tagged member of
both client VLANs.
ProCurve Switch 5308xl(config)# access-controller b client-ports a2,a6
ProCurve Switch 5308xl(config)# access-controller b
ProCurve Switch 5308xl(access-controller-B)# show vlans
Downlink:
VLAN ID VLAN Name
2000 VLAN2000
2001 VLAN2001
Uplink:
VLAN ID VLAN Name
1 DEFAULT_VLAN
ProCurve Switch 5308xl(config)# show vlans 2000
Status and Counters - VLAN Information - Ports - VLAN 2000
802.1Q VLAN ID : 2000
Name : VLAN2000
Status : Port-based
Voice : No
Port Information Mode
---------------- -------- ------------ --------- -
A2 Untagged Disable
BDP Tagged Disable
Figure 12-5. Configuring A Downlink Client Port
Depending on how many VLANs are already configured in the 5300xl switch,
the following messages may occur:
Access Controller xl Module for the Series 5300xl Switches
Configuring the Access Controller xl Module
Ports
A2,BDP
A6,BDP
Ports
A1,A3-A5,A7-A24,BUP
Unknown VLAN Status
Down
Up
