ATA Command Description
5.1.15. Request Sense—03H
Bit ->
7
Command (7)
C/D/H (6)
1
Cyl High (5)
Cyl Low (4)
Sec Num (3)
Sec Cnt (2)
Feature (1)
This command requests an extended error code after a command ends with an error. Table 5-19 defines the valid
extended error codes for the CompactFlash Memory Card Series product. The extended error code is returned to the
host in the Error Register. This command must be the next command issued to the CompactFlash Card following the
command that returned an error.
Extended Error Code
00h
01h
09h
20h
21h
2Fh
35h, 36h
11h
18h
05h, 30-34h, 37h, 3Eh
10h, 14h
3Ah
1Fh
0Ch, 38H, 3Bh, 3Ch, 3Fh Corrupted Media Format
03h
5-14
Table 5-18. Request Sense
6
5
4
03H
X
1
Drive
Table 5-19. Extended Error Codes
No Error Detected
Self Test OK (No Error)
Miscellaneous Error
Invalid Command
Invalid Address (Requested Head or Sector Invalid)
Address Overflow (Address Too Large)
Supply or generated Voltage Out of Tolerance
Uncorrectable ECC Error
Corrected ECC Error
Self Test or Diagnostic Failed
ID Not Found
Spare Sectors Exhausted
Data Transfer Error/Aborted Command
Write/Erase Failed
®
CompactFlash
Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION
3
2
X
X
X
X
X
X
Description
1
0
