Product Specifications
2.3. System Performance
All performance timings assume the CompactFlash Memory Card Series controller is in the default (i.e., fastest)
mode.
Start Up Times
Active to Sleep Delay
Data Transfer Rate
To/From Flash
Data Transfer Rate
To/From Host
Controller Overhead
NOTE: The Sleep to Write and Sleep to Read times are the times it takes the CompactFlash Memory Card to exit
sleep mode when any command is issued by the host to when the card is reading or writing. CompactFlash
Memory Cards do not require a reset to exit sleep mode (see Section 1.7.5).
2.4. System Reliability
MTBF (@ 25°C)
Preventive Maintenance
Data Reliability
2.5. Physical Specifications
Refer to Table 2-5 and see Figure 2-1 for CompactFlash Memory Card physical specifications and dimensions.
2-2
Table 2-3. Performance
Reset to ready:
Command to DRQ 50 msec maximum
Table 2-4. Reliability
>1,000,000 hours
None
<1 non-recoverable error in 10 14 bits read
<1 erroneous correction in 10 20 bits read
Table 2-5. Physical Specifications
Weight: 11.4 g (.40 oz) typical, 14.2 g (.50 oz) maximum
Length: 36.40 ± 0.15 mm (1.433 ±.006 in)
Width: 42.80 ± 0.10 mm (1.685 ±.004 in)
Thickness: 3.3 mm ± 0.10 mm (.130 ±.004 in) (Excluding Lip)
®
CompactFlash
Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION
Sleep to write:
2.5 msec maximum
Sleep to read:
50 msec maximum
50 msec typical
400 msec maximum
Programmable
20.0 MBytes/sec burst
16.0 MBytes/sec burst
