4
Viewing and
Configuring System
Information
C
ONFIGURING
S330/S310 M
A
PPLICATIONS
This chapter tells you how to configure the CPU, modules, ports, and related
applications for the SuperStack II PathBuilder S330 and SuperStack II PathBuilder
S310 WAN access switches (PathBuilder S330/S310 switch) so that the devices can
pass traffic. It contains the following sections:
Viewing and Configuring System Information
Using the Configuration Management Menu
Using the List Card Menu
Configuring the Management CPU
Configuring the CTX
Configuring Ports
Configuring the T1/E1 Interface
Configuring the OC3/STM-1 Port
Configuring the DS3/E3 UNI Module
Configuring the Serial Interface
Configuring the Ethernet Interface
Configuring the Ethernet 10/100 Module
Configuring the CBR Module
Configuring the Voice Compression Module
Configuring Virtual Circuits
Managing the Video Dial Feature
The System Administration menu, shown in Figure 55, includes options that allow
you to view and configure system information. In addition to using this menu for
initial configuration, as described in Chapter 3, you can:
Specify general system information.
View system parameters for the RS-232 port.
View the current firmware version.
Download new firmware.
Update the flash file system.
Reset the interface card.
View an equipment list.
P
B
ATH
UILDER
, P
ODULES
,
ORTS
AND
