SiE12-411
Model
Rated Capacity
Front Panel Color
m³/min
Air Flow Rates
(cfm)
Type
Fan Motor Output
Speed
Air Direction Control
Air Filter
Running Current (Rated)
Power Consumption (Rated)
Power Factor
Temperature Control
Dimensions (H×W×D)
Packaged Dimensions (W×D×H)
Weight
Gross Weight
Operation
H/M/L/SL
Sound
Sound Power H
Heat Insulation
Liquid
Piping Connection Gas
Drain
Drawing No.
Specifications
FTKS60BVMB
6.0kW Class
White
H 16.2 (572)
M 13.6 (480)
L 11.4 (402)
SL 10.2 (360)
Cross Flow Fan
W
Steps 5 Steps, Silent and Auto
Right, Left, Horizontal and Downward
Removable-Washable-Mildew Proof
A 0.18
W
% 96.6
Microcomputer Control
mm 290×1,050×238
mm 1,147×366×337
kg
kg
dBA 45/41/36/33
dBA
Both Liquid and Gas Pipes
φ
mm
φ
mm 12.7
φ
mm 18.0
3D040782A
43
40
12
17
63
6.4
Specifications
50Hz, 230V
FTKS71BVMB
7.1kW Class
White
16.7 (590)
14.2 (501)
11.6 (409)
10.6 (374)
Cross Flow Fan
43
5 Steps, Silent and Auto
Right, Left, Horizontal and Downward
Removable-Washable-Mildew Proof
0.20
45
96.4
Microcomputer Control
290×1,050×238
1,147×366×337
12
17
46/42/37/34
63
Both Liquid and Gas Pipes
φ
6.4
φ
15.9
φ
18.0
3D040783A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
23
