Protocol
WAN Interface
WAN IP
Private IP
Subnet Mask
After finishing all the settings here, please click OK to save the configuration.
Specify the transport layer protocol. It could be TCP, UDP, or
ALL for selection.
Choose the WAN interface for such address mapping profile.
This is the source IP of a packet captured on the WAN side and
sent by a NAT host specified in the Private IP field.
The drop down menu contains WAN interface IPs and WAN
IP alias IPs.
This is the source IP of a NAT host which wishes to send
packets to the WAN side and have source address as
configured in the WAN IP field.
Select a value of subnet mask for private IP address.
122
Vigor2110 Series User's Guide
