Monitoring and Analyzing Switch Operation
Traffic Mirroring
B-38

Quick Reference to Local Mirroring Set-Up

These commands configure or remove mirroring where the mirroring source
and destination are on the same switch. For command syntax details, refer to
the pages listed after each heading. For each mirroring Source Switch option:
The mirror command identifies the destination for the mirroring session.
■
The interface and vlan commands identify the mirroring source; that is,
■
the interface type, the traffic to mirror, and the mirroring session to use.
To Configure or Remove a Local Mirroring Session
Mirroring Session Number, Exit Port, and (Optional) Session Name (Page B-43)
mirror < 1 - 4 > port < port-# > [ name < name-str >]
no mirror < 1 - 4 >
The no form of the command removes the mirroring session and any mirroring
source previously assigned to that session by the following commands.
To Configure or Remove Mirroring on Port/Trunk/Mesh Interfaces for Local Ses­
sions:
Directional Criteria Selects Traffic To Mirror (Page B-48).
[no] interface < port/trunk/mesh > monitor all < in | out | both > mirror
< 1 - 4 | name-str > [< 1 - 4 | name-str > < 1 - 4 | name-str > < 1 - 4 | name-str >]
Inbound ACL Criteria Selects Traffic To Mirror (Page B-52).
[no] interface < port/trunk/mesh > monitor ip access-group < acl-name > in mirror
< 1 - 4 | name-str > [< 1 - 4 | name-str > < 1 - 4 | name-str > < 1 - 4 | name-str >]
The < name-str > option applies only if the specified mirroring session has
already been configured with the name < name-str > option in the mirror
command.
The no form of the command removes the < port/trunk/mesh > mirroring source
from the specified session, but leaves the session available for other assign­
ments.
To Configure or Remove Mirroring on VLAN Interfaces for Local Sessions:
Directional Criteria Selects Traffic To Mirror (Page B-50)
[no] vlan < vid-# > monitor all < in | out | both > mirror < 1 - 4 | name-str >
[< 1 - 4 | name-str > < 1 - 4 | name-str > < 1 - 4 | name-str >]
Inbound ACL Criteria Selects Traffic To Mirror (Page B-54).
[no] vlan < vid-# > monitor ip access-group < acl-name > in mirror < 1 - 4 | name-str >
[< 1 - 4 | name-str > < 1 - 4 | name-str > < 1 - 4 | name-str >]
The < name-str > option applies only if the mirroring session has already been
configured with the name < name-str > option in the mirror command.
