Max Tx Rate - Specifies the maximum transmit rate of the device through this field.
Enable Wireless Radio - Select or deselect this check box to allow or deny wireless
stations to access the device.
Click the Survey button to detect the SSIDs in the local area.
Note:
To apply any settings you have altered on the page, please click the Save button, and then you
will be reminded to reboot the device.
4) Bridge with AP: This mode can bridge the AP and up to 4 APs also in bridge mode to
connect two or more wired LANs.
Figure 6-10 Wireless Settings in Bridge with AP mode
Wireless Network Name (also called SSID) - Identifies your wireless network name. Create
a name up to 32 characters and make sure all wireless points in the wireless network with the
same SSID. The default SSID is TP-LINK_POCKET_3020_XXXXXX (XXXXXX indicates the
last unique six characters of each device's MAC address). This value is case-sensitive. For
example, TEST is NOT the same as test.
Region - Select your region from the pull-down list. This field specifies the region where
the wireless function of the device can be used. It may be illegal to use the wireless
function of the device in a region other than one of those specified in this field. If your
TL-MR3020
Portable 3G/4G Wireless N Router
-204-
