Multitech MultiModem rCell MTCBA-H-EN2 User Manual page 39

On the
3. Packet Filters > DNAT Configuration
Allow Access –
External Service –
LAN IP –
Internal Service –
Pre DNAT Service –
Post DNAT IP –
Post DNAT Service –
Internal Source –
Click the Save button to save this configuration.
4. Save –
Note:
which you have made changes. The device will save all the settings and reboot the PC.
Multi-Tech Systems, Inc. MultiModem rCell User Guide
Select the original target network/host of the IP packets that you now want rerouted. The
original target network/host is the one previously defined in the Network Configuration section.
Any
Example:
Select the External Service that you want allowed.The service must be defined in the
Service Configuration section.
Select the LAN IP to which the packets are to be diverted. Only one host can be defines as the
destination.
Select the Internal Service to be the destination.
Select the service for the Pre-DNAT destination. This service was just defined in the
Service Configuration section.
MeterPort
Example:
Select the destination to which the IP packets are to be diverted. Only one host can be
defined as the Post DNAT destination.
MeterIP
Example:
Select the service for the Post DNAT configuration.
MeterPort
Example:
Select the source address for packets that going to be sent. If you do not want to change
the address, select NOCHANGE.
NOCHANGE
Example:
You must click Save and Restart once you have completed and submitted all the screens on
Chapter 3 – Using the Web Management Software
screen, define the DNAT rule.
39
