Screen Parts

Menu Bar Submenu Title

Screen Buttons

Click this button to return to the Home screen.
Home:
Click this button to display the Wizard Setup screen on which you can quickly set up your wireless
Wizard Setup:
Router with basic configuration settings.
Click this button to Logout and return to the login screen.
Logout:
Click this button to display the Help text.
Help:
Submenus
The submenus display on the left side of the screen.
The following table shows the sub-menu selections under each main menu category.
IP Setup PPP
General Config. PPP Config.
HTTP Config. Wakeup
DDNS Config. on Call
SNTP Config. Power On
Static Routes Config.
Remote Config. Router
Commands
Multi-Tech Systems, Inc. MultiModem rCell User Guide
Submenu List
Networks & Packet Filters GRE
Services
Network Packet Filters
Configuration DNAT Config.
Service Advanced
Configuration
Chapter 3 – Using the Web Management Software
DHCP Server Tools
Tunnels
GRE Tunnels Subnet Settings
GRE Routes Fixed Addresses
Screen Buttons
Screen Name
Screen Input Area
Statistics
& Logs
Tools Ethernet
Service Status PPP
Firmware PPP Trace
Upgrade SysInfo
Load Config. DHCP Stat
Save Config. GRE Stat
Modem Info
