Chapter 2 – Activation and Installation
After clicking the Wizard Setup selection, the Wizard Setup screen displays.
5.
Wizard Setup
A minimum router configuration is provided using the Wizard Setup. This provides a quick way to enter and save information
needed to create a connection to the internet. The table below provides the information for the minimum configuration.
IP Configuration
IP Address
Mask
DNS
PPP Configuration
PPP
Dial-on-
Demand
Idle Time Out
Dial Number
APN
Init String
PPP Authentication
Authentication
Type
User Name
Password
A Note About the Access Point Name
The APN (Access Point Name) is assigned by your HSDPA wireless service provider, but you may have to ask
for it. An access point is an IP network to which a wireless Router connects. The Web Management software
asks for the APN on the Wizard Setup screen and the PPP screen.
18
The default is 192.168.2.1. To change it, simply enter your own IP address.
The default is 255.255.255.0
Enter the primary DNS IP address for the system. The default is 0.0.0.0
The default is disable. To connect to the internet, you have to enable PPP.
Depending on the model, commands may need to be issued to the integrated
cellular modem before connecting to the wireless service. To issue commands to
the integrated cellular modem, PPP must be disabled and telnet port 5000 used.
The default is disable.
Sets the amount of time the PPP link stays active before disconnecting. Setting
the value to zero causes the link to stay active continuously.
Enter the dial number. This number connects you to the Internet.
For HSDPA, the number is *99***1#.
For HSDPA, enter the APN (Access Point Name). The APN is assigned by your
wireless service provider.
You can set up to 4 router initialization strings.
Click the button corresponding to the authentication protocol you want to use to
negotiate with the remote peer. PAP, CHAP, or PAP-CHAP.
Default = PAP-CHAP
Enter the PPP User Name. This name authenticates the remote peer. The
default is ipmodule.
Enter the PPP Password. This password authenticates the remote peer.
The default is ipmodule.
Multi-Tech Systems, Inc. MultiModem rCell User Guide
