10
SET MODE

■ Quick set mode

Mode Set mode item
RF POWER
SSB MIC GAIN
DATA MODE
RF POWER
KEY SPEED
CW CW PITCH
SIDE TONE LEVEL
SIDE TONE LIMIT
RF POWER
TWIN PEAK FILTER
RTTY RTTY MARK TONE
RTTY SHIFT
RTTY KEY POLARITY
RF POWER
AM MIC GAIN
DATA MODE
RF power
This item adjusts the RF output power. The RF output
power can be adjusted from L (Low), 1% to 100% in 1%
steps.
Mic gain
This item adjusts microphone gain from 0% to 100% in
1% steps.
Data mode
This item turns the data mode ON or OFF.
When the data mode is turned ON, the audio input from
the [ACC] connector* is used for transmission instead of
[MIC] connector and the speech compressor function is
turned OFF.
* The desired connector can be selected. (p. 77)
on : Data mode operation is enabled.
(" " appears.)
oF : Data mode operation is disabled.
(" " disappears.)
71
Default setting
100%
50%
OFF
100%
20WPM
600Hz
30%
ON
100%
OFF
2125Hz
170Hz
NORMAL
100%
50%
OFF
(all modes)
(SSB/AM modes)
(SSB/AM modes)
100% (default)
50% (default)
OFF (default)
