D Convenient functions for transmit

• VOX (voice operated transmit) (p. 53)
➥ Push to turn the VOX function ON or OFF.
VOX
• " " appears when the VOX function is ON.
➥ Push and hold
VOX
set mode, then rotate [DIAL] to adjust the VOX
gain, anti VOX gain or VOX delay.
• Rotate [M-CH] to select an item.
D About 5 MHz band operation (USA version only)
Operation on the 5 MHz band is allowed on 5 dis-
crete frequencies and must adhere to the following:
• USB mode
• Maximum of 50 watts ERP
• 2.8 kHz bandwidth
It is the operator's responsibility to set all controls so
that the transmission in this band meets the stringent
conditions under which we may use these frequen-
cies.
NOTE: We recommend that you store these fre-
quencies, mode and filter settings into the mem-
ory channel for easy recall.
for 1 sec. to enter the VOX
(Effective Radiated Power)
RECEIVE AND TRANSMIT
• Speech compressor (p. 57)
➥ Push to turn the speech compressor ON
COMP
or OFF.
• " " appears when the speech compressor is ON.
➥ Push and hold
COMP
pression level set mode, then rotate [DIAL] to ad-
just the compression level.
IC-7200
Display Frequency*
5.33050 MHz
5.34650 MHz
5.36650 MHz
5.37150 MHz
5.40350 MHz
* The channel center frequencies that are specified
by the FCC, show the center frequency of their
passband. However, the IC-7200 displays carrier
point frequency, so set 1.5 kHz below from FCC
channel center frequency.
To assist you in operating the 5 MHz band cor-
rectly within the rules specified by the FCC,
transmission is impossible on any 5 MHz band
frequency other than the 5 frequencies indicated in
the table above.
for 1 sec. to enter the com-
FCC Channel
Center Frequency*
5.33200 MHz
5.34800 MHz
5.36800 MHz
5.37300 MHz
5.40500 MHz
