D Programmable tuning steps

The operating frequency can be changed in steps of
(0.1, 1, 5, 9 or 10 kHz selectable) for quick tuning.
MODE
TUNER

D Selecting the programmable tuning step

Programmable tuning steps are available to suit your
operating requirements.
These tuning steps are:
• Selectable from 0.1, 1, 5, 9 and 10 kHz
MODE
TUNER
ANF
NB NR
METER
2
V/M 1 A/B 3
SPLIT
1.8 = 3.5 7
4 5 6
MW M-CL AGC
10 14 18
7 8 9
COMP SCAN VOX
28
21 24
.
TS
0 F-INP ENT
RIT MNF
GENE 50
BAND
FILTER
P.AMP
ATT
M-CH/RIT
SPCH
SET
[DIAL]
ANF
NB NR
METER
V/M 1 A/B 2 3
SPLIT
1.8 = 3.5 7
4 5 6
MW M-CL AGC
10 14 18
7 8 9
COMP SCAN VOX
21 24 28
.
TS
0 F-INP ENT
RIT MNF
GENE 50
BAND
FILTER
P.AMP
ATT
M-CH/RIT
SPCH
SET
[DIAL]
q Push to turn the programmable tuning func-
TS
tion ON.
• "Z" appears.
Programmable tuning step indicator
w Rotate [DIAL] to change the frequency in pro-
grammed kHz steps.
e Push again to turn the programmable tuning
TS
function OFF.
• "Z" disappears.
r Rotate [DIAL] for normal tuning, if desired.
q Push to turn the programmable tuning func-
TS
tion ON.
• "Z" appears.
Programmable tuning step indicator
w Push and hold for 1 sec. to enter the tuning
TS
step set mode.
e Rotate [DIAL] to select the desired tuning step
from 0.1, 1, 5, 9 or 10 kHz.
r Push to exit the tuning step set mode.
TS
t Rotate [DIAL] to change the frequency according
to the set tuning step.
y Push to turn the programmable tuning func-
TS
tion OFF.
• "Z" disappears.
