Icom IC-7200 Instruction Manual page 84

10
SET MODE
■ Set mode (Continued)
Mic Up/Down Speed
This item sets the rate at which frequencies are scanned
when the microphone [UP]/[DN] keys are pushed and
held.
HI : High speed (50 tuning steps/sec.)
Lo : Low speed (25 tuning steps/sec.)
SSB/CW Synchronous Tuning
This item turns the displayed frequency shift function
from ON or OFF.
When this function is set to ON, the received signal
will remain the same even when the operating mode is
changed between SSB and CW.
The amount of frequency shift will change according to
the CW pitch setting.
on : The displayed frequency shifts when the operating
mode is changed between SSB and CW.
oF : The displayed frequency does not shift.
CW Normal Side
Selects the carrier point of CW mode from LSB and USB.
L (LSB) : LSB is the normal mode.
U (USB) : USB is the normal mode.
Break-In
This item selects break-in type for CW operation.
Full break-in (QSK) activates the receiver between trans-
mitted dots and dashes. This is useful when operating
contests, when "fast responses" are common.
Semi break-in keeps the receiver quiet between dots and
dashes and automatically returns to receive after a pre-
set time from when you stop keying.
When break-in is turned off, the key or paddle can gener-
ate side tones (selectable in quick set mode) but will not
transmit.
oF : No break-in operation.
SE (Semi) : Semi break-in operation.
FL (Full) : Full break-in operation
Break-In Delay
This item adjusts break-in delay time for CW semi
break-in operation.
The delay time is selectable from 0.2 to 13.0 (dots) in 0.1
(dots) steps.
79
.
High (default)
OFF (default)
LSB (default)
OFF (default)
7.5 dots (default)
