Command Sub command
1A
0303
Set/read Key speed level setting
(0=6 wpm to 255=60 wpm)
0304
Set/read CW Pitch setting (0=300
Hz to 120=900 Hz; 5 Hz steps)
0305
Set/read CW side tone setting
(0=0% to 255=100%)
0306
Set/read CW side tone level limit
(0=OFF, 1=ON)
0307
Set/read Twin peak filter
(0=OFF, 1=ON)
0308
Set/read RTTY mark frequency
(0=1275 Hz, 1=1615 Hz, 2=2125 Hz)
0309
Set/read RTTY shift width
( 0=170 Hz, 1=200 Hz, 2=425 Hz,
3=850 Hz)
0310
Set/read RTTY keying polarity
(0=Normal, 1=Reverse)
0311
Set/read LCD brightness
(0=OFF, 1=Dark, 2=Bright)
0312
Set/read confirmation beep
(0=OFF, 1=ON)
0313
Set/read band edge beep
(0=OFF, 1=ON)
0314
Set/read beep gain
(0=0% to 255=100%)
0315
Set/read beep gain limit
(0=OFF, 1=ON)
0316
Set/read [RF/SQL] control set
(0=Auto, 1=SQL, 2=RF+SQL)
0317
Set/read meter peak hold
(0=OFF, 1=ON)
0318
Set/read quick split set
(0=OFF, 1=ON)
0319
Set/read split lock set
(0=OFF, 1=ON)
0320
Set/read transmit frequency monitor
with [RIT] key set
(0=OFF, 1=ON)
0321
Set/read tuner auto start set
(0=OFF, 1=ON)
0322
Set/read PTT tune start set
(0=OFF, 1=ON)
0323
Set/read MOD input connector
during DATA OFF
( 0=MIC, 1=ACC, 2=MIC+ACC,
3=USB)
0324
Set/read MOD input connector
during DATA ON
( 0=MIC, 1=ACC, 2=MIC+ACC,
3=USB)
0325
Set/read MOD input gain from USB
(0=0% to 255=100%)
0326
Set/read speech level
(0=0% to 255=100%)
0327
Set/read speech language
(0=English, 1=Japanese)
0328
Set/read speech speed
(0=Slow, 1=Fast)
0329
Set/read S-level speech
(0=OFF, 1=ON)
0330
Set/read speech capability with
[MODE] key operation
(0=OFF, 1=ON)
0331
Set/read scan speed set
(0=Slow, 1=Fast)
0332
Set/read scan resume set
(0=OFF, 1=ON)
Description
CONTROL COMMAND
Command Sub command
1A
0333
Set/read main dial auto TS (0=OFF,
1=Low, 2=High)
0334
Set/read 1/4 dial speed set (0=OFF,
1=ON)
0335
Set/read mic. UP/DOWN speed
(0=Low, 1=High)
0336
Set/read SSB/CW synchronous
tuning function (0=OFF, 1=ON)
0337
Set/read CW carrier point set
(0=LSB, 1=USB)
0338
Set/read break-in set (0=OFF,
1=semi BK-IN, 2=full BK-IN)
0339
Set/read break-in delay time set
(20=2.0 d to 130=13.0 d)
0340
Set/read CW keyer dot/dash ratio
(28=1:1:2.8 to 45=1:1:4.5)
0341
Set/read CW paddle polarity
(0=Normal, 1=Reverse)
0342
Set/read CW keyer type
( 0=Straight, 1=Bug-key, 2=ELEC
Key)
0343
Set/read MIC UP/DOWN keyer
(HM-36) set (0=OFF, 1=ON)
0344
Set/read SSB mode selectability
( 0=OFF: inhibition, 1=ON:
selectable)
0345
Set/read CW mode selectability
( 0=OFF: inhibition, 1=ON:
selectable)
0346
Set/read RTTY mode selectability
( 0=OFF: inhibition, 1=ON:
selectable)
0347
Set/read AM mode selectability
( 0=OFF: inhibition, 1=ON:
selectable)
0348
Set/read CI-V transceive set
(0=OFF, 1=ON)
0349
Set/read reference frequency set
(0=0% to 255=100%)
0350
Set/read noise blanker level set
(0=0% to 255=100%)
0351
Set/read noise blanker width set
(0=0% to 255=100%)
0352
Set/read NR level set
(0=0 to 15=15)
0353
Set/read VOX gain set
(0=0% to 255=100%)
0354
Set/read Anti-VOX gain set
(0=0%, 255=100%)
0355
Set/read VOX delay set
(0=0.0 sec. to 20=2.0 sec.)
0356
Set/read speech compressor level
(0=0 to 10=10)
04
Send/read DATA mode with filter set
(see next page for detail)
05
Set/read DSP filter shape
(0=Sharp, 1=Soft)
06
Set/read manual notch width
(0=Wide, 1=Mid., 2=Nar.)
1C
00
Set/read the transceiver's condition
(0=Rx, 1=Tx)
01
Set/read antenna tuner condition
( 0=OFF, 1=ON, 2=Start tuning or
while tuning)
14
