7 High-speed Counters

System configuration

Wiring Example
Encoder (power
supply: 24 VDC)
Example: E6B2-CWZ6C
NPN open-collector output
24-VDC Power
Supply
+24 V
PLC Setup
Use the following procedure to enable high-speed counter 0.
1
Click the Set Button in the High-speed Counters Area.
The High-speed Counter Detailed Settings Dialog Box will be displayed.
7-44
Phase A
Black
White Phase B
Orange Phase Z
+Vcc
Brown
0 V ( COM )
Blue
Motor start:
CIO 2960.02
0 V
A1 A2 A3 A4 A5 A6
B1 B2 B3 B4 B5 B6
Connector-Terminal Block
Conversion Unit
XW2D-40G6
Motor operation input:
CIO 2961.00
Motor low speed input: CIO 2961.01
Example: Inverter
CJ2M CPU Unit
Pulse I/O
Module
Connecting Cable
XW2Z-@@@K
A13 A14 A15 A16 A17 A18 A19 A20
B13 B14 B15 B16 B17 B18 B19 B20
CJ2M CPU Unit Pulse I/O Module User's Manual
Normal stop
position output:
CIO 2961.02
Error stop
position output:
CIO 2961.03
