CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
1A 050174 see p. 14-12 Send/read antenna selection for 22.00
050175 see p. 14-12 Send/read antenna selection for 26.00
050176 see p. 14-12 Send/read antenna selection for 30.00
050177 see p. 14-12 Send/read antenna selection for 45.00
050178 00 or 01 Send/read antenna temporary mem-
050179 00 to 02 Send/read antenna selection
050180 00 or 01 Send/read usage for ANT2
050181 00 or 01 Send/read usage for ANT3
050182 00 to 02 Send/read usage for ANT4
00 to 20 Send/read VOX delay
050183
00 to 03 Send/read VOX voice delay
050184
050185 00 to 09 Send/read NB depth (00=1 to 09=10)
050186 0000 to
0255
050187 00 to 03 Send/read screen saver set
050188 00 to 02 Set/read screen saver type
050189 00 to 02 Set/read meter response setting
050190 00 to 03 Set/read FFT scope averaging set for
050191 see p. 14-11 Set/read FFT scope waveform color
050192 00 to 03 Set/read FFT scope averaging set for
050193 see p. 14-11 Set/read FFT scope waveform color
050194 00 or 01 Set/read PSK AFC function tuning
050195 00 or 01 Set/read APF type
050196 00 or 01 Send/read external keypad set for
050197 00 or 01 Send/read external keypad set for
00 or 01 Voice memory transmission set for
050198
050199 00 or 01 Memory keyer transmission set for
050200 00
01
02
03
04
05
050201 00 to 06 Send/read APF AF level.
Description
to 26.00 MHz band
to 30.00 MHz band
to 45.00 MHz band
to 60.00 MHz band
ory set (00=OFF, 01=ON)
(00=OFF, 01=Manual, 02=Auto)
(00=OFF, 01=TX/RX)
(00=OFF, 01=TX/RX)
(00=OFF, 01=TX/RX, 02= RX)
(00=0.0 sec. to 20=2.0 sec.)
( 00=OFF, 01=Short, 02=Mid.,
03=Long)
Send/read NB width
(0000=1 to 0255=100)
( 00=OFF, 01=15 min., 02=30 min.,
03=60 min.)
(00=Bound, 01=Rotation, 02=Twist)
(00=SLOW, 01=MID, 02=FAST)
RTTY decoder
(00=OFF, 01=2, 02=3, 03=4)
set for RTTY decoder
PSK decoder
(00=OFF, 01=2, 02=3, 03=4)
set for PSK decoder
range (00=±8 Hz, 01=±15 Hz)
(00=SHARP, 01=SOFT)
RTTY memory (00=OFF, 01=ON)
PSK memory (00=OFF, 01=ON)
[F1]–[F4] on the keyboard
(00=OFF, 01=ON)
[F1]–[F4] on the keyboard
(00=OFF, 01=ON)
Send/read time-out timer OFF
Send/read 3 min. time-out timer
Send/read 5 min. time-out timer
Send/read 10 min. time-out timer
Send/read 20 min. time-out timer
Send/read 30 min. time-out timer
(00=0 dB to 06=+6dB)
Cmd. Sub Cmd. Data
1A 050202 0000 to
0255
050203 00 to 05 Send/read the TX Delay setting (HF)
050204 00 to 05 Send/read the TX Delay setting (50M)
050205 00, 01
050206 0000 to
0223
050207
050208 00, 01
050209 000001 to
065535
050210 000001 to
065535
050211 000001 to
065535
050212 00, 01
050213 see p. 14-13 Send/read Network radio name
050214 00 to 04 Send/read the maximum AF sample
050215 00 to 02 Send/read the AF codecs for remote
050216 00, 01
050217 00, 01
050218 00 to 04 Send/read the maximum modulation
050219 00 to 02 Send/read the modulation codecs for
050220 00, 01
050221 see p. 14-11 Send/read the waveform outline color
14-8
Description
Send/read LAN MOD output level
(0000=0% to 0255=100%)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
Send/read the Shutdown function.
( 00=Shutdown, 01=Standby/Shut-
down)
Send/read the transceive CI-V Ad-
dress for LAN to REMOTE in hexadec-
imal code.
(0000=00h to 0223=DFh)
Send/read the default gateway set
( 0000000000000001=0.0.0.1 to 0255
025502550254=255.255.255.254, or
FF=Blank)
Send/read the remote control capabil-
ity. (00=OFF, 01=ON)
Send/read the control port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the serial port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the audio port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the internet access line
setting.
( 00=FTTH (Fiber To The Home),
01=ADSL/CATV)
(up to 16-character)
rates for remote stations.
( 00=8 kHz, 01=12 kHz, 02=16 kHz,
03=24 kHz, 04=48 kHz)
stations.
( 00=LPCM 8bit,
01=LPCM 8bit, u-law 8bit,
02=LPCM 8bit, u-law 8bit, LPCM 16bit)
Send/read the stereo operation capa-
bility for remote stations.
(00=1ch, 01=2ch)
Send/read the network TX audio set-
ting for remote stations.
(00=OFF, 01=ON)
sample rates for remote stations.
( 00=8 kHz, 01=12 kHz, 02=16 kHz,
03=24 kHz, 04=48 kHz)
remote stations.
( 00=LPCM 8bit,
01=LPCM 8bit, u-law 8bit,
02=LPCM 8bit, u-law 8bit, LPCM 16bit)
Send/read the waveform outline indi-
cation on the spectrum scope.
(00=Fill, 01=Fill+Line)
for receiving signal.
