CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
14 11 0000 to
0255
12 0000 to
0255
13 0000 to
0255
14 0000 to
0255
15 0000 to
0255
16 0000 to
0255
17 0000 to
0255
18 0000 to
0255
19 0000 to
0255
15 01 00
01
02 0000 to
0255
11 0000 to
0255
12 0000 to
0255
13 0000 to
0255
14 0000 to
0255
15 0000 to
0255
16 0000 to
0255
16 02 00
01
02
12 00
01
02
03
22 00
01
32 00
01
02
03
40 00
01
41 00
01
42 00
01
43 00
01
44 00
01
45 00
01
Description
Send/read [AGC] level
(0000=max. CCW to 0255=max. CW)
Send/read NB level
(0000=0%, 0255=100%)
Send/read [DIGI-SEL] position
(0000=max. CCW to 0255=max. CW)
Send/read DRIVE gain
(0000=0%, 0255=100%)
Send/read Monitor gain
(0000=0%, 0255=100%)
Send/read VOX gain
(0000=0%, 0255=100%)
Send/read Anti VOX gain
(0000=0%, 0255=100%)
Send/read [CONTRAST] position
(0000=max. CCW to 0255=max. CW)
Send/read BRIGHT level
(0000=0%, 0255=100%)
Read squelch condition (squelch close)
Read squelch condition (squelch open)
Read S-meter level
(0000=S0, 0120=S9, 0241=S9+60 dB)
Read RF power meter
(0000=0 W, 0143=100 W, 0212=200 W)
Read SWR meter
( 0000=SWR1.0, 0048=SWR1.5,
0080=SWR2.0)
Read ALC meter
(0000=0, 0120=Max.)
Read COMP meter
(0000=0 dB, 0130=15 dB, 0241=30 dB)
Read VD meter
(0151=44 V, 0180=48 V, 0211=52 V)
Read ID meter
(0000=0 A, 0165=10 A, 0241=15 A)
Preamp OFF
Preamp 1 ON
Preamp 2 ON
AGC OFF selection
AGC FAST selection
AGC MID selection
AGC SLOW selection
Noise blanker OFF
Noise blanker ON
Audio peak filter OFF
Audio peak filter WIDE ON
( 320 Hz is selected when SHARP
APF is set)
Audio peak filter MID ON
( 160 Hz is selected when SHARP
APF is set)
Audio peak filter NAR ON
( 80 Hz is selected when SHARP APF
is set)
Noise reduction OFF
Noise reduction ON
Auto notch function OFF
Auto notch function ON
Repeater tone OFF
Repeater tone ON
Tone squelch OFF
Tone squelch ON
Speech compressor OFF
Speech compressor ON
Monitor function OFF
Monitor function ON
Cmd. Sub Cmd. Data
16 46 00
01
47 00
01
02
48 00
01
4C 00
01
4D 00
01
4E 00
01
4F 00
01
50 00
01
55 00
01
02
56 00
01
57 00
01
02
58 00
01
02
17
see p. 14-12 Send CW messages*
18 00
01
19 00
1A 00 see p. 14-13 Send/read memory contents
01 see p. 14-10 Send/read band stacking register con-
02 see p. 14-10 Send/read memory keyer contents
03 00 to 49 Send/read the selected filter width
04 00 to 13 Send/read the selected AGC time
050001 00 to 10 Send/read SSB TX Tone (Bass) level
050002 00 to 10 Send/read SSB TX Tone (Treble)
050003 00 to 10 Send/read SSB RX Tone (Bass) level
050004 00 to 10 Send/read SSB RX Tone (Treble)
050005 00 to 10 Send/read AM TX Tone (Bass) level
1
* In the CW mode, if the [TRANSMIT] or an external TX switch is ON, or
the Break-in function is ON, a message will be transmitted as CW code
when you send it from your PC.
2
The power ON command (18 01) is available only when the trans-
*
ceiver is standby mode.
14-4
Description
VOX function OFF
VOX function ON
BK-IN function OFF
Semi BK-IN function ON
Full BK-IN function ON
Manual notch function OFF
Manual notch function ON
VSC function OFF
VSC function ON
AGC VR function OFF
AGC VR function ON
DIGI-SEL function OFF
DIGI-SEL function ON
Twin peak filter OFF
Twin peak filter ON
Dial lock function OFF
Dial lock function ON
15 kHz roofing filter selection
6 kHz roofing filter selection
3 kHz roofing filter selection
SHARP selection for DSP filter type
SOFT selection for DSP filter type
WIDE selection for manual notch
width
MID selection for manual notch width
NAR selection for manual notch width
WIDE selection for SSB transmit
bandwidth
MID selection for SSB transmit band-
width
NAR selection for SSB transmit band-
width
1
Turn OFF the transceiver.
2
Turn ON the transceiver.*
Read the transceiver ID
tents
( SSB, CW, PSK: 00=50 Hz to
40=3600 Hz; RTTY: 00=50 Hz to
31=2700 Hz; AM: 00=200 Hz to
49=10 kHz)
constant (00=OFF, 01=0.1/0.3 sec.,
13=6.0/8.0 sec.)
(00 =–5 to 10=+5)
level (00=–5 to 10=+5)
(00 =–5 to 10=+5)
level (00=–5 to 10=+5)
(00 =–5 to 10=+5)
