Siemens MC35 Command Set page 200

AT Command Set
<mode> 0 unlock
<passwd> password
<class>
<status> 0 off
Reference Note
GSM 07.07, See also specification of AT+CLCK in GSM 07.07 and further details in Chapter
4.21.
GSM 02.04,
The command has been implemented with the full set of <class> parameters ac-
GSM 02.88,
cording to the definition of "AT+CLCK" in GSM 07.07. For actual applicability of a
Siemens
specific "call forwarding" facility <fac> to a specific service or service group (a
specific <class> value) please consult table A.1 of GSM 02.04.
MC35_ATC_01_V05.00
1 lock
2 query status
integer or sum of integers each representing a <class> of information:
1 voice
2 data
4 fax
8 short message service
16 data circuit sync
32 data circuit async
64 dedicated packet access
128 dedicated PAD access
x combination of some of the above classes.
For example, the default setting 7 represents the sum of the in-
tegers 1, 2 and 4 (call barring for voice, data and fax). The
value 255 covers all classes. If the <class> parameter is omit-
ted, the default value 7 is used.
See examples in 4.21.3 for the correct handling of class numbers.
<class> 2 (data) comprises all those <class> values between 16 and 128,
that are supported both by the network and the MS. This means, a set-
ting made for <class> 2 applies to all remaining data classes (if sup-
ported). In addition, you can assign a different setting to a specific class.
For example, you can activate Call Barring for all data classes, but deac-
tivate it for a specific data class.
1 on
Page 200 of 256 15.07.2002
