Wireless LAN PC Card Specifications

Product Name
Model Number
Host Interface
Dimensions
Weight
Frequency Band
(Central frequency)
Number of Channel
Operating Voltage
Current Consumption
Spreading
Data rate
Transmit Power
Modulation
Security
Standards
Media Access Protocol
Environmental Conditions
Operating Range
-120
11 Mbps Wireless LAN PC Card
AN-WC11B (RUNTKA025WJZZ)
PCMCIA TYPE II
" × 4 " × " (54 (W) × 115 (D) × 6 (H) mm)
2 1 ⁄ 1 ⁄ 1 ⁄
8 2 4
0.091 lbs (40 g)
2.4000 – 2.4835 GHz
1–11 (Channels that can be used vary depending on the country.)
3.3 V ± 5% or 5 V ± 5%
Typ. 240 mA, Max. 300 mA
DS-SS (Direct Sequence Spread Spectrum)
11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps (Auto-Switch)
10 dBm (Normal Temp Range) 13 dBm (Max)
11 Mbps and 5.5 Mbps: CCK
2 Mbps: DQPSK
1 Mbps: DBPSK
WEP (64 bit/128 bit) (not compatible with the projector)
IEEE802.11b
CSMA/CA with ACK
Temperature Range 32 to 131°F (0 to 55°C) (Operating)
Humidity Max. 95% Non-condensing
Open Space: 197' to 394' (60 to 120 m); Indoor: 98' to 197' (30 to 60 m)
The transmission distance varies with the transmission speed and the surrounding
environment.
