Page 11: Introduction
To ensure that this machine is used correctly and safely, carefully read the Quick Guide [Copy/Print/Fax/Scan/Box Operations] before using the machine. ACKNOWLEDGEMENT: KONICA MINOLTA, KONICA MINOLTA Logo, and The essentials of imaging are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS, INC. PageScope and bizhub are registered trademarks or trademarks of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.
Page 12: Special Notice To User
If trouble is experienced with this equipment FK-502, for repair or warranty information, please contact the Konica Minolta dealer location where you purchased this equipment. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
Page 13: For New Zealand
Contents Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. If you home has specially wired alarm equipment connected to the telephone line, ensure the installation of FK-502 does not disable you alarm equipment.
Page 14: For Europe
Contents For Europe The Facsimile has been approved in accordance with Council Decision 1999/5/ EC for pan-European single terminal connection to the public switched telephone network (PSTN). However, due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network terminal point.
Page 15: Send A Fax (Faxing
Contents Send a fax (Faxing) The basic procedure for sending a fax is described below. Sending a fax In order to use the fax functions, the optional fax kit must be installed. Press [Fax/Scan] key on the control panel to enter fax mode. The Fax/Scan screen is displayed.
Page 16 Contents Specify functions to be used if required. – Scan Settings screen – For details on scan settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings" on page 6-2. – Original Settings screen – For details on original settings, refer to "Original Settings" on page 6-3. –...
Page 17 Contents Enter the fax number of the recipient on the keypad. – If an incorrect number has been entered, touch [Delete] and then correct the number. – When [C] (clear) key is pressed, all entered numbers are deleted. Press [Start] key on the control panel. –...
Page 18: Available Features
Contents Available features Attaching and sending the total page count The total page count for the number of pages in the original sent can be attached to and sent with the original when using Quick Memory TX. This is useful for confirming whether the entire original has been correctly sent or not.
Page 19: Erasing Shadows
Contents Erasing shadows Shadows that appear on the top, bottom, left and right of originals when faxing items such as booklets can be erased. For details, refer to page 6-10. Width of erasure Ordinary Frame erasure transmission transmission Specifying a scanning area size on the original It is possible to specify a scanning area size for originals to be faxed.
Page 20: Sending An Original With Fold Lines
Contents Sending an original with fold lines Originals with original sizes that cannot be correctly detected due to fold lines can still be sent at the correct size. For details, refer to page 6-26. Sending long originals Originals longer than 432 mm (17 inch) can be sent. For details, refer to page 6-28.
Page 21: Sending Faxes By Command From The Recipient
Contents Sending faxes by command from the recipient An original loaded or stored on the machine can be sent when a command is made by the recipient. For details, refer to page 8-6. Receiver Sender Releasing ECM mode This function allows you to release ECM mode and send faxes to reduce transmission time. For details, refer to page 6-33.
Page 22: Using A Confidential Box
Contents Using a confidential box An original to be sent to or received by a specific person can be transmitted using a confidential box. For details, refer to page 6-46. Sender Receiver Confidential Sending password-protected faxes If the receiving machine is set up for closed communication, it is possible to send a password-protected fax to the recipient.
Page 23: Saving To A Box
Contents Saving to a box A scanned original can be saved from the Fax/Scan screen to a box created in the hard disk of this machine. The box is specified as the destination instead of a fax number. Files saved in a box can also be sent as faxes. For details, refer to page 1-11.
Page 24: Explanation Of Manual Conventions
Contents Explanation of manual conventions C650 x-23...
Page 25 Contents C650 x-24...
Page 26: Descriptions Of Original Documents And Paper
Contents Descriptions of original documents and paper The descriptions used in this manual for documents and paper are explained below. Whenever document and paper dimensions are mentioned in this manual, the value shown as Y in the illustration refers to the width, and the value shown as X refers to the length.
Page 27: User's Guides
MFP with applications. In order to use the functions effectively, please read this User’s Guide. The following models support the advanced function. bizhub C650/C550/C451/C353/C253/C203 C650 x-26...
Page 28: Before Using This Machine
Before using this machine...
Page 29: Precautions
Before using this machine Before using this machine Precautions This machine cannot transmit or receive color faxes. The following types of telephone lines can be connected to this machine. Local telephone lines (Including fax communication networks) PBX (Private branch exchange two-line systems) Be sure to check the following for the telephone line to be used.
Page 30: Using The Control Panel
Before using this machine Using the control panel Control panel Name Description Touch panel Displays various setting screens and messages. Main Power indicator Lights up in green when the [Main Power switch] is ON. Sub power switch Used to turn power ON/OFF to the control panel. When turned off, the machine enters a state where it conserves energy.
Page 31 Before using this machine Name Description [Enlarge Display] key Press to enter Enlarge Display mode.If authentication is performed with Page- Scope Authentication Manager, it does not enter Enlarge Display mode. For details, refer to the User’s Guide [Enlarge Display Operations]. [Accessibility] key Press to display the screen for specifying user accessibility functions.
Page 32: Fax Mode Screens
Before using this machine Fax Mode screens The Fax/Scan screen appears when the [Fax/Scan] key on the control panel is pressed. The displayed destination or function can be selected by using your finger to lightly touch the button displayed on the screen. Name Description [Check Job] button...
Page 33 Before using this machine Note The display positions of the [Address Book], [Direct Input], [Job History] and [Address Search] tabs differ depending on the settings specified for the Scan/Fax Settings parameters in Utility mode. For details, refer to "Setting the initial state of Fax/Scan screen (Scan/Fax Settings)" on page 10-13. If "Confirm Address (TX)"...
Page 34: Initial Settings
Before using this machine Initial settings After installation, the following settings must be made in order to use fax functions. If the following settings are not correctly made, fax communications may not be possible. Please ensure these settings are registered. Date/Time Settings Date/Time Settings Specify the current date and time.
Page 35: Convenient Function Settings
Before using this machine Convenient function settings By registering destinations that you fax often in the Address Book destinations or Group destinations, and registering Program destinations for fax tranmssion settings that are used often, the registered details can be recalled by simply touching the registered button. Address Book destinations By registering destinations that you fax often in the Address Book destinations, you can recall destinations by simply touching the registered button.
Page 36: User Authentication And Account Track
Before using this machine User authentication and account track This machine can be set so that an account or user name and a password must be entered in order to use the machine. Contact the administrator for details on the account or user name for using the machine. With user authentication (machine authentication) Type in the user name and password, and then touch [Login] or press the [Access] key.
Page 37 Before using this machine Note If "Prohibited Functions When Authentication Error" in Administrator mode is set to "Mode 2" and a user enters an incorrect password the specified number of times, that user is locked out and can no longer use the machine.
Page 38: Fax Reception Using A Box
Before using this machine Fax reception using a box In this machine, by using PC-FAX RX function or Memory RX function, the received original can be saved in a box on the hard disk without printing it. Additionally, if a confidential original is received, the original is automatically saved in the confidential box on the hard disk.
Page 39 Before using this machine Box name Function System User Bulletin Board These boxes are used for registering originals for viewing. Originals registered User Box in the Bulletin Board User Box can be sent via polling according to polling commands from the recipient. Detail For details on the Bulletin Board User Box, refer to "Polling after specify- ing the original (Bulletin board)"...
Page 40: Pc-Fax Rx Function Operations
Before using this machine PC-FAX RX function operations Originals received by PC-FAX RX function are saved in a forced Memory RX User Box or a Public/Personal User Box (box no.1 to 999999999) on the hard disk. The box for saving the received original is specified with the [PC-FAX RX Setting] in the Utility mode. Refer to the following table for details related to [PC-FAX RX Setting] and reception methods.
Page 41: Transmission And Reception Using An Extension Line
Before using this machine Transmission and reception using an extension line Transmission and reception using 2 lines can be carried out by installing the fax multi line. Note Please note the following points when installing a fax multi line. The off-hook function can be used by Line 1 only (standard line). Reception using Line 2 (extension line) is only by auto reception.
Page 42: Usage As A Reception-Only Line
Before using this machine Usage as a reception-only line Line 2 (extension line) can be set to receive only. When line 2 is set exclusively for reception, only line 1 is used for sending. This is convenient when you wish to separate your sending and reception lines. Note Line 1 is used for both transmission and reception and cannot be set as reception-only line.
Page 43: To Send A Fax
To send a fax...
Page 44: General Fax Operation
To send a fax To send a fax General fax operation This section contains information about general operations for sending a fax. Detail Color faxes cannot be sent and received. Use scan functions to send a colored fax. For details on the scan functions, refer to the User’s Guide [Network Scanner Operations].
Page 45 To send a fax Touch [Scan Settings], specify the desired function and touch [OK]. – Scan Setting functions are specified as follows at the time of purchase. [Original Type]: Text/Photo (Printed Photo) [Simplex/Duplex]: 1-Sided [Resolution]: 200×200dpi (Fine) [Density]: Standard – [File Type] is not available in Fax mode.
Page 46 To send a fax Touch [Communication Settings], specify the desired function and touch [Close]. – For details on communication settings, refer to "Communication Settings" on page 6-4. Specify the recipient’s fax number. – For details on procedures for specifying a fax number, refer to "Specifying only one destination" on page 2-13 and "Specifying multiple destinations (Sequential broadcast transmission or broadcast transmission)"...
Page 47 To send a fax – When the Destination Check Display Function function is set, the Destination Settings screen is displayed. Confirm that the destination is correct and touch [Send]. For details, refer to the "Sending the fax after reconfirming the destination (Destination Check Display Function)" on page 6-41. –...
Page 48: Loading The Original
To send a fax Loading the original The original can be loaded in the ADF or on the original glass in this machine. If the original is loaded in the ADF, the original is scanned automatically from the ADF. Loading the original in the ADF If the ADF is used, originals with multiple pages can be automatically scanned.
Page 49: Faxing A Multi-Page Original Using The Original Glass
To send a fax Close the ADF slowly. Faxing a multi-page original using the original glass All pages of a multi-page original that cannot be loaded into the ADF can be faxed together using the original glass. Press [Fax/Scan] key to display the Fax/Scan screen. Specify the destination.
Page 50 To send a fax Load the original on the original glass or in the ADF, and touch [Scan Settings], [Separate Scan], [OK] and then press [Start] key. – When using the original glass and the ADF, the ADF is given priority. –...
Page 51: Specifying Scanning Conditions
To send a fax Specifying scanning conditions Touching [Scanning Settings] on the Fax/Scan screen displays [Original Type], [Simplex/Duplex], [Resolution] and [Density], and enables you to specify transmission conditions for the original to be sent. Note [File Type] cannot be used in Fax mode. Specifying scanning settings Note You cannot specify different transmission conditions for different pages within one original.
Page 52: Simplex/Duplex
To send a fax There are 5 types of original type settings. At the time of purchase, original type is set to [Text/Photo]. [Text]: Touch when scanning text-only originals. If you select this mode for scanning originals with photos, none of the image’s intermediate colors will be reproduced, and the image will darken. [Text/Photo]: Touch when originals with text and photos (half tone) mixed together, are to be scanned.
Page 53: Resolution
To send a fax Resolution Sets the scanning resolution for the original. There are 4 types of resolution settings. At the time of purchase, resolution is set to [200 × 200 (Fine)]. [200×100 (Standard)]: Touch when you wish to reduce transmission time. [200×200 (Fine)]: Touch when scanning normal originals.
Page 54 To send a fax At the time of purchase, density is set to [Standard]. [Light]: Touch for light-density scanning. [Standard]: Touch for standard-density scanning. [Dark]: Touch for darker-density scanning. C650 2-12...
Page 55: Specifying Only One Destination
To send a fax Specifying only one destination The following methods are possible for specifying one destination only. Specifying from registered destinations Specifying by direct input Specifying from job history Specifying from program destinations Detail Refer to "Specifying from registered destinations" on page 2-13 regarding methods for specifying from the registered destinations.
Page 56: Searching For A Registered Destination (Index Button)
To send a fax Searching for a registered destination (Index button) Destinations can be searched for using the specified search word when a destination is registered. Detail The index default display can be changed with the Address Book Index Default Setting. For details, refer to "Setting the initial state of Fax/Scan screen (Scan/Fax Settings)"...
Page 57: Searching For Registered Destinations (Detail Search)
To send a fax Touch [Address Type]. Select the address type. – If the button for the desired destination type is not displayed, touch [←] or [→]. – The default display settings of the [Address Book] tab can be changed to address type with the Default Address Book setting.
Page 58 To send a fax Touch [Detail Search]. – When a destination applicable to the entered information is not found, "Search Result: 0" is displayed and no button is on the screen. Touch [Name] or [Address]. – Enter the name or fax number using the keyboard displayed on the screen and touch [OK]. –...
Page 59: Specifying By Direct Input
To send a fax Specifying by direct input A destination can be specified by direct input even if the destination is not registered with the address book. Note IIf "Manual Destination Input" in Utility mode is set to "Restrict" or if "Manual Destination Input" in the Default Function Permission or Function Permission screen in User Authentication Settings is set to "Restrict", the [Direct Input] tab will not appear.
Page 60: Specifying From The Job History
To send a fax Specifying from the job history It is possible to specify number from the job history, which lists numbers you have sent faxes to in the past (from the previous five numbers). Touch [Job History] on the Fax/Scan screen. –...
Page 61 To send a fax Touch [Address Search] in the Fax/Scan mode screen. Touch [Search]. – If multiple LDAP servers are registered, a screen for selecting a server appears. From the list, select the server to be searched, and then touch [OK]. –...
Page 62: Performing An Ldap Search (Advanced Search)
To send a fax Performing an LDAP search (Advanced Search) A destination can be searched for on the specified LDAP server based on the specified search conditions. Detail If "Manual Destination Input" in Utility mode is set to "Restrict" or if "Manual Destination Input "in the Default Function Permission screen (displayed from the User Authentication Settings screen) is set to "Restrict", the [Address Search] tab does not appear.
Page 63 To send a fax – Touch [OR], and then select the keyword search condition in the screen that appears. The corresponding addresses on the specified LDAP server are searched for. Select the desired address in the list, and then touch [OK]. The destination is specified.
Page 64: Specifying Multiple Destinations (Sequential Broadcast Transmission Or Broadcast Transmission)
To send a fax Specifying multiple destinations (Sequential broadcast transmission or broadcast transmission) An original can be sent to multiple destinations with one operation. This function is called a sequential broadcast transmission or broadcast transmission. The following procedure describes how to specify multiple destinations. Specifying from registered destinations Specifying by direct input Specifying from the job history...
Page 65 To send a fax Touch the desired group button. Multiple destinations are specified. Detail To cancel the group key display, touch [Favorite]. In the Default Address Book setting, the default display settings of the [Address Book] tab can be changed to "Address Type". The group key appears as one of the address types. For details, refer to "Setting the initial state of Fax/Scan screen (Scan/Fax Settings)"...
Page 66: Sending A Fax Using A Program Destination
To send a fax Sending a fax using a program destination When a program address has been registered, a fax can be sent by specifying the registered program button. If transmission settings (Original type and original specification etc.) are registered by a program key, a fax can be sent by simply touching that button without the need for specifying function settings each time.
Page 67 To send a fax Touch the page button in which the desired program destination is registered, and then touch [OK]. – Touch [↑] or [↓] to display the previous or next page button screen. Touch the desired program button and touch [OK]. –...
Page 68: Checking The Settings
To send a fax Checking the settings The destination specified can be confirmed in the broadcast destination list in the left panel of the screen, and setting details checked in the setting details screen. To check the settings The destination specified can be confirmed by the broadcast destination list in the left panel of the screen. Follow the procedures indicated below to check destination and setting details.
Page 69 To send a fax – If the [Delete] is touched, the selected destination is deleted. – It is possible to register directly entered destinations by touching [Store Address]. For details, refer to "Registering the fax number in Address Book" on page 9-3. –...
Page 70 To send a fax – For details of communication settings, refer to "Communication Settings" on page 6-4. After checking has been completed, touch [Close] until it returns to the Fax/Scan screen. – When Scan Settings, Original Settings or Communication Settings are changed, the Scan Settings screen, Original Settings screen or Communication Settings screen appears.
Page 71: Operations While Scanning
To send a fax Operations while scanning If original size cannot be detected If the original size cannot be detected, the scan size screen is displayed. Set the original size. Touch the Original Size button and then touch [OK]. For European model (Metric) For North American model (Inch) Touch [Close] and then touch [OK].
Page 72: Original Auto Rotation
To send a fax Original auto rotation An A4 or 8-1/2 × 11 original loaded in the v orientation is automatically rotated and sent in the w orientation. When A4 or 8-1/2 × 11 document pages are loaded in the v orientation to be sent together with longer document pages, the A4 or 8-1/2 ×...
Page 73: When Unable To Send Fax
To send a fax When unable to send fax If the fax cannot be sent because the recipient’s line is busy, it can be transmitted again by using the redial function. The redial function of this machine has auto redial, manual redial and resend functions. Note The destination cannot be changed for either auto redial or manual redial in the Current Jobs list.
Page 74: Manual Redial (Fax Retransmit User Box)
To send a fax – When fax multi line is installed The redial screen is displayed. Touch [OK]. Redialing of the selected job is performed. Manual redial (Fax Retransmit User Box) Even if the auto redial frequency exceeds the one specified by the Line Parameter Setting, if the job cannot be sent, it is saved in the Fax Retransmit User Box.
Page 75 To send a fax Select the job you wish to resend and touch [Fax]. Confirm the destinations displayed in Broadcast Destinations list and touch [Start] or press [Start] key. The job is resent. Note It is also possible to change the destination. After resending, the job is automatically deleted from the Fax Retransmit User Box.
Page 76: Reserving A Transmission
To send a fax 2.10 Reserving a transmission It is possible to reserve the next transmission while the machine is communicating or printing. This function is called reserved transmission. Note [Off-Hook] cannot be used for reserved transmission. Touch [Next Fax/Scan Job]. –...
Page 77: Sending A Fax While Confirming The Status Of The Recipient's Machine (Manual Transmission)
To send a fax 2.11 Sending a fax while confirming the status of the recipient’s machine (Manual transmission). Use this operation when sending a fax while checking the status of the receiving machine. This is called a manual transmission. Quick Memory TX cannot be used with manual transmission. Press [Fax/Scan] key to display the Fax/Scan screen.
Page 78: Aborting Transmission
To send a fax 2.12 Aborting transmission Operations for aborting transmissions differ according to whether the job is being executed (including reserved jobs) or timer transmission has been reserved. Note Jobs to be transmitted that are stored in this machine are called reserved jobs. Aborting a job during transmission It is possible to abort the transmission of jobs being transmitted (including reserved jobs) by using the following procedure.
Page 79 To send a fax – Touch [↓] or [↑], to display the next screen or previous screen. Touch [Yes] and then touch [OK]. The job is deleted. Touch [Close] until it returns to the Fax/Scan screen. C650 2-37...
Page 80: Checking Reserved Jobs To Be Transmitted
To send a fax 2.13 Checking reserved jobs to be transmitted The transmission reservation status stored in the memory can be checked using the job list displayed on the screen. Touch [Job List]. Touch [Job Details]. Touch the [Send]. Touch [Current Job]. –...
Page 81: Checking Transmission Results
To send a fax 2.14 Checking transmission results It is possible to check transmission results with the job list. The following items can be checked on the Job History list screen. Job History list (Send) The history of fax-transmitted and scan-transmitted jobs is displayed. Note The jobs that have been forwarded or relayed after having been received by fax are also listed in the Job History list of [Send].
Page 82 To send a fax Touch [Detail] to check detailed information about the job. For broadcasting transmissions, "Broadcast" is displayed in the destination. The detailed information of the job can be verified by selecting the job from the list and touching [Details]. Touch [Job List].
Page 83 To send a fax Check the transmission result. – Job History List (Send) – Job History List (Receive) When you have completed checking, touch [Close]. The machine returns to the Fax/Scan screen. C650 2-41...
Page 84: Memory Transmission And Quick Memory Transmission
To send a fax 2.15 Memory transmission and quick memory transmission There are two ways of sending originals using this machine: quick memory transmission and memory transmission. Memory transmission In this method, a whole original is scanned in advance, stored in the memory, and then the fax is transmitted. The total number of pages is attached automatically to the page numbering in the transmission source information, and an image of the first page of the sent original is included in the TX Result Report.
Page 85 To send a fax Specify the destination. – For details regarding specifying destinations, refer to "Specifying only one destination" on page 2-13. Press [Start] key. – If the fax cannot be sent because the recipient’s line is busy, the recipients number is redialed. For details regarding redialling, refer to "When unable to send fax"...
Page 86: Attaching The Total Page Count To A Sent Fax (Total # Of
To send a fax 2.16 Attaching the total page count to a sent fax (Total # of Pages) Using the original page count function enables you to attach with page numbering the total number of pages recorded at the transmission source to the total page numbering when sending a fax using quick memory transmission.
Page 87 To send a fax Touch [Total # of Pages (Quick Memory TX)]. Enter the original count using the keypad and then touch [OK]. – Touch [No] to release the settings Touch [OK]. The original page count is set and the machine returns to the Fax/Scan screen. Specify other settings if required.
Page 88: Sending A Fax After Specifying A Time (Timer Tx)
To send a fax 2.17 Sending a fax after specifying a time (Timer TX) Timer TX is a function that specifies a time for transmission. It is economical to transmit at discounted calling times, such as late at night or early in the morning. Note Following functions cannot be used simultaneously.
Page 89 To send a fax – Touch [No] to release timer transmission settings. Touch [OK] twice, and then touch [Close]. Timer TX is set, and the machine returns to the Fax/Scan screen. Specify other settings if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings"...
Page 90: Faxing Overseas (Overseas Tx)
To send a fax 2.18 Faxing overseas (Overseas TX) Overseas TX is a function that transmits the information with a slow transmission speed if the original is to be sent to areas where communication conditions are bad. The procedure for overseas transmission is explained here. Note Following functions cannot be used simultaneously.
Page 91 To send a fax When fax multi line is not installed When fax multi line is installed Touch [OK] and then touch [Close] on the next screen. Overseas TX is set and the machine returns to the Fax/Scan screen. – International dialing codes can be registered together with telephone numbers in the Address Book and Program destinations.
Page 92: Fax Header Settings
To send a fax 2.19 Fax Header Settings Position set for Fax Header The original to be sent is recorded as follows at the recipient’s end. When the Header Position is set to [Inside Body Text]. From : MFP01 To:123456789 05/25/2006 13:22 #138 P.001/001 When the Header Position is set to [Outside Body Text].
Page 93: Print Receiver's Name Setting
To send a fax Print Receiver’s Name Setting It is possible to set whether receiver’s name is printed at the Fax Header or not. When [Print Receiver’s Name] is ON, the sender’s name and receiver’s name is printed. From : MFP01 To:123456789 05/25/2006 13:22 #138 P.001/001 When [Print Receiver’s Name] is OFF, the sender’s name and Sender Fax Name is printed.
Page 94: Faxing After Previewing
To send a fax 2.20 Faxing after previewing Previewing allows you to view an image of the scanned document in the touch panel before it is sent. Note Previewing is not available when performing the quick memory transmission operation. Preview screen From the Preview screen, the scanned document can be rotated if the orientation is incorrect or settings specified before scanning can be changed.
Page 95: Page Rotation
To send a fax Detail If the display size is changed, the finishing status cannot be viewed. Page Rotation In Page Rotation, a preview image can be rotated by 180 degrees to correct wrong original direction. Touch [Rotate current page] to rotate the currently displayed page by 180 degrees. Touch [Select page(s) to rotate] to display the list of scanned pages.
Page 96: View Finishing
To send a fax View Finishing Touch [View Finishing] to display the finishing settings in the preview image of the output with icons and texts, and finishing status can be checked. Press [View Finishing] again to cancel the finishing view of the preview image.
Page 97: Previewing
To send a fax Note The keys that appear in the Change Setting screen may be different, depending on the selected settings. Parameter Description Document Select either 1-sided or 2-sided. If the "Cover + 2-Sided" is specified, [Cover + 2-Sided] also appears.
Page 98 To send a fax Press the [Start] key. Scanning of the document begins, and the Preview screen appears. Check the preview image. – To change the settings, touch [View Pages], and then continue with step 9. – To begin the transmission, continue with step 10. –...
Page 99: Reception
Reception...
Page 100: Reception Modes
Reception Reception Reception modes This machine has the following reception modes. Select the setting appropriate for the telephone line in use. Auto reception (Fax only mode) Specify this mode when the telephone line is to be used only for faxing. Refer to "Auto reception (Fax only mode)"...
Page 101: Auto Reception (Fax Only Mode)
Reception Auto reception (Fax only mode) Specify this mode when the telephone line is to be used only for faxing. Faxes are automatically received on detection of the set number of rings. During reception "Receiving" is displayed on the message display part of the screen.
Page 102: Manual Reception (Telephone Only Mode)
Reception Manual reception (Telephone only mode) This mode should be set when an external telephone is connected and many telephone calls are received. This mode operates when the [Receive Mode] is set to [Manual RX] in the [Line Parameter Setting] of the Utility mode.
Page 103: When Unable To Receive Fax
Reception When unable to receive fax An error message is displayed if a fax cannot be received. Refer to "Fax cannot be sent" on page 4-2, and then perform the indicated operation. The error message display disappears after pressing [Stop] key. Detail If the external telephone bell keeps on ringing, [Receive Mode] may be set to [Manual RX] in the [Line Parameter Settings] of the Utility mode.
Page 104: Temporary Memory Reception
Reception Temporary memory reception Temporary memory reception If the received original cannot be printed because of a paper misfeed, etc., the received original is saved in the memory until it can be printed. This function is known as temporary memory reception. When problems such as paper misfeeds, etc.
Page 105: Maintaining A Record During Reception
Reception Maintaining a record during reception When printing the received fax, the page size of the received original is compared with the size of the loaded paper, and the fax is printed by reducing the size at the specified reduction rate or by reducing the size so as to fit the loaded paper.
Page 106 Reception Width of the re- Reception infor- Length of the received original ceived original mation recording position [OFF] or [Inside 0 - 150 151 - 305 306 - 390 391 or more Body Text] [Outside Body 0 - 141 142 - 296 297 - 381 382 or more Text]...
Page 107 Reception When [Print Separate Fax Pages] is [OFF]: The printing paper is sequentially selected from the top row. 5.5 × 8.5 v 8.5 × 11 w 8.5 × 11 v 8.5 × 14 w 11 × 17 w Appropriate paper Paper order 5.5 ×...
Page 108 Reception When [Print Separate Fax Pages] is [ON]: The printing paper is sequentially selected from the top row. 5.5 × 8.5 v 8.5 × 11 w 8.5 × 11 v 8.5 × 14 w 11 × 17 w Appropriate paper Paper order 5.5 ×...
Page 109: Printing To Equal Size
Reception Pages are not divided if [Print Separate Fax Pages] is [ON] and [TX/RX Settings] in the Utility mode is set as follows. Tray is set to [Tray Selection for RX Print] When [Min. Reduction for RX Print] is set to [Full Size] When [Print Paper Selection] is set to [Fixed Size] or [Priority Size] When [Duplex Print (RX)] is [ON] Refer to "Settings of transmission and reception mode (TX/RX Settings)"...
Page 110: Method Of Printing During Reception
Reception Method of printing during reception The relationship between the actual printing of the fax and the paper size of the received fax is as follows. Detail When [Duplex Print (RX)] is [ON], the fax can be printed on both sizes of the paper. Refer to "Settings of transmission and reception mode (TX/RX Settings)"...
Page 111: Footer Setting
Reception Footer Setting When [Footer Position] is set to [Inside Body Text] or [Outside Body Text] in [Header/Footer Position] in the Utility mode, reception information (date, time, reception number, page number) is printed on the received original as the footer. Detail Refer to "Specifying the method of setting the transmission source/reception information (Header/Footer Position)"...
Page 112: Troubleshooting
Troubleshooting...
Page 113: Fax Cannot Be Sent
Troubleshooting Troubleshooting Fax cannot be sent If the fax cannot be sent, refer to the following table, and then perform the indicated operations. If the fax still cannot be sent correctly, even after performing the described operations, contact your technical representative.
Page 114: Fax Cannot Be Received
Troubleshooting Fax cannot be received If the fax cannot be received, refer to the following table, and then perform the indicated operations. If the fax still cannot be received correctly, even after performing the described operations, contact your technical representative. Detail For error messages refer to "Error Messages"...
Page 115: Error Messages
Troubleshooting Error Messages If there is a machine malfunction, the error screen appears with one of the following error messages. Refer to the following table, and then perform the indicated operations. If the correct transmission is still not possible even after performing the described operations, contact your technical representative.
Page 116: If "Contact Your Service Rep." Is Displayed (Service Call)
Troubleshooting If "contact your Service Rep." is displayed (Service Call) When there is a problem that cannot be remedied by the customer, "contact your Service Rep." message is displayed on the screen. (Service Call Screen) Normally, the telephone and fax number of the technical representative of the customer is displayed on the centre of the service call screen.
Page 117: Specifications
Specifications...
Page 118 Specifications Specifications Specifications The specifications for the main fax-related products are listed below. In order to incorporate improvements, these product specifications are subject to change without notice. Item Specifications Image memory capacity 1024 MB (Standard) Number of stored pages 10000 sheets (When an A4 size original with about 700 characters is stored with "Fine"...
Page 119: Useful Transmission Functions
Useful transmission functions...
Page 120: List Of Functions On The Settings Screen
Useful transmission functions Useful transmission functions List of functions on the Settings screen Following functions are displayed on the Scan Settings, Original Settings and Communication Settings screens. Scan Settings Detail For details on Basic settings, refer to "Specifying scanning settings" on page 2-9. For details on [Separate Scan], refer to "Faxing a multi-page original using the original glass"...
Page 121: Original Settings
Useful transmission functions Screen display Description [Application] [Scan Size] Sends the fax after specifying the scan size. This is useful when you want to fax only a portion of the original. →page 6-17 [Annotation] The original can be saved in the box with date/time and filing number at the same time as the transmission of the Fax.
Page 122: Communication Settings
Useful transmission functions Screen display Description [Total # of Pages (Quick Memory TX)] Function to send the fax with the total number of pages of the original during quick memory transmission. →page 2-44 [Despeckle] Function that reduces the effect that the dust from the left partition glass has on the scan data when scanning an original from the ADF.
Page 123 Useful transmission functions Screen display Description [Communication/Recep- [Quick Memory TX] Function that scans and transmits one page at a time. →page 2-42 tion Method Settings] [Polling RX] Function that sends an original loaded in the sender’s fax machine or an original reserved for polling transmission, when a request is sent by the recipient.
Page 124: Sending A Fax After Adjusting The Density Of Background Color (Background Removal)
Useful transmission functions Sending a fax after adjusting the density of background color (Background Removal) Background Removal Background Removal is a function that adjusts the background color density of the original. If original background is colored, the background of the transmission data becomes black when it is scanned. In such cases, original can be sent after adjusting the background color density of the transmission data.
Page 125 Useful transmission functions Touch [Dark] button to darken the background color of original, and [Light] button to lighten the background. – If [Auto] is selected, the original scanning speed falls as the reserved operation for background adjustment is carried out for each page of the original. Touch [OK].
Page 126: Sending The Fax After Emphasizing The Character Edges (Sharpness)
Useful transmission functions Sending the fax after emphasizing the character edges (Sharpness) Sharpness Sharpness is the function that adjusts the intensity of the edges. When the text in the original is blurred, the clarity of the text can be increased by adjusting the sharpness with "+". Moreover, the sharpness can be decreased with "-".
Page 127 Useful transmission functions To increase the clarity of the edges, touch [ ] on + side, and to smoothen the text, touch [ on - side. Touch [OK]. Returns to Quality Adjustment screen. Touch [OK]. Returns to Scan Settings screen. Touch [OK].
Page 128: Sending The Fax After Removing The Black Shadow (Frame Erase)
Useful transmission functions Sending the fax after removing the black shadow (Frame Erase) Frame Erase When original is scanned while the ADF is open, there may be a black shadow around the original at the time of scanning the booklet original and the original may be faxed with the black shadow. Frame Erase is a function that erases the black shadow on Top, Bottom, Right, and Left sides of the original when a booklet is scanned.
Page 129 Useful transmission functions Select [Top], [Left], [Frame: Right], [Bottom], [Frame] and set the respective erase values. – When a frame on a specify position is not to be erased, touch the button of the desired frame and then touch [None]. When [None] is to be cancelled, press the keypad or [+] button and specify the erase quantity.
Page 130 Useful transmission functions Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings" on page 6-2. – For details on Original Settings, refer to "Original Settings" on page 6-3. –...
Page 131: Sending Double Page Originals Page By Page From Right To Left (Book Copy)
Useful transmission functions Sending double page originals page by page from right to left (Book Copy) Book Copy When the book or catalog etc. is sent by fax, the original is divided into right and left pages and is sent page by page.
Page 132 Useful transmission functions Touch [Book Copy]. Select the desired end settings and then touch [OK]. – Touch [No] to cancel book-copy function. – If [Separation], [Front Cover] or [Front + Back Cover] is selected, [Binding Position] is displayed. Select to match the binding orientation of the original and then touch [OK]. –...
Page 133 Useful transmission functions For setting the Fold erase values in North American models (Inch) with fraction display, touch [ change the numerator and denominator and the touch [-] or [+]. In case of setting the Center Erase values for numeric display in North American models (Inch), press keypad or [-] and [+].
Page 134 Useful transmission functions – When [Front Cover] is selected, double page text original is scanned page by page after the Front cover is scanned. SURVEYOR’S REPORT – When [Front + Back Covers] is selected, Back cover is scanned after the Front cover and finally the double page text original is scanned page by page.
Page 135: Sending A Fax After Specifying The Scan Size Of The Original (Scan Size)
Useful transmission functions Sending a fax after specifying the scan size of the original (Scan Size) Scan Size Scan Size is a function to send the fax after specifying the scan size of the original. When the paper width on the recipient’s side is smaller than the paper size of the original that is sent, the original is reduced and then printed.
Page 136 Useful transmission functions Touch the button for specifying original size to match the original. – Touch [↑] or [↓] to display the next or previous fixed size screen. – The following standard paper sizes are not available with fax transmissions. A5 w, A6 w, 5-1/2 ×...
Page 137 Useful transmission functions – If the fax could not be sent, refer to "Fax cannot be sent" on page 4-2. The scanned original is stored in the memory as a scheduled job and transmission is started. C650 6-19...
Page 138: Copying The Original At The Same Time As Sending The Fax (Send & Print)
Useful transmission functions Copying the original at the same time as sending the Fax (Send & Print) Send & Print It is a function to copy at the same time as Fax transmission. Number of copies can be increased and 2-Sided printing and staple margins can be set.
Page 139 Useful transmission functions – Touch [Corner] or [2 Position] to specify the staple margins and touch [None] to cancel the staple margins. Touch [Close]. Returns to Scan Settings screen. Touch [OK]. Returns to Fax/Scan screen. Set other functions if required. –...
Page 140: Confirming That The Original Is Scanned (Tx Stamp)
Useful transmission functions Confirming that the original is scanned (TX Stamp) TX Stamp When the fax is to be sent using ADF, whether each page of the original has been scanned or not can be confirmed by adding the completion stamp to the scanned original. A 4 mm (1/4 inch) diameter pink colored stamp is added on the bottom edge of the front side of the original.
Page 141 Useful transmission functions Touch [TX Stamp]. – Touch [TX Stamp] once again to cancel the settings. Touch [Close]. Returns to Scan Settings screen. Touch [OK]. Returns to Fax/Scan screen. Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings"...
Page 142: Sending An Original Of Varying Sizes By A Single Operation (Mixed Original)
Useful transmission functions Sending an original of varying sizes by a single operation (Mixed Original) Mixed Original Mixed Original is a function that detects each original size when an original with varying sizes is loaded. Transmitted and reproduced in the same sizes as the original pages at the destination You set original pages of...
Page 143 Useful transmission functions – Load the original pages into the ADF so that the top of the pages is toward the back or the left side of the machine. Lateral guide Touch [Original Settings]. Touch [Mixed Original]. – Touch [Mixed Original] again to cancel the settings. Touch [OK].
Page 144: Sending An Original With Folds (Z-Folded Original)
Useful transmission functions 6.10 Sending an original with folds (Z-Folded Original) Z-Folded Original Function to fax originals with original sizes that cannot be correctly detected due to fold lines. Note Use ADF. Z-Folded Original cannot be faxed using original glass. Originals from the second original onwards are transmitted with the size same as that of first original.
Page 145 Useful transmission functions Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings" on page 6-2. – For details on Original Settings, refer to "Original Settings" on page 6-3. –...
Page 146: Sending A Long Original (Long Original)
Useful transmission functions 6.11 Sending a long original (Long Original) Long Original Function that sends pages having a length of more than 432mm (17 inch). Original of a length of up to 1000mm (39-1/4 inch) can be sent by specifying Long Original setting. Note Use ADF.
Page 147 Useful transmission functions Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings" on page 6-2. – For details on Original Settings, refer to "Original Settings" on page 6-3. –...
Page 148: Specifying The Binding Position (Binding Position)
Useful transmission functions 6.12 Specifying the binding position (Binding Position) Binding Position Function to specify the binding position settings when a double sided original is to be sent using ADF. There are top and left binding position for a double-sided original and position of the back of the original is different. Top bind Transmission Left bind...
Page 149 Useful transmission functions Touch [Top], [Left] or [Auto] to select the margins of a double-sided original. Touch [OK]. Returns to Original Settings screen. Touch [OK]. Returns to Fax/Scan screen. Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings"...
Page 150: Faxing By Reducing The Effect Of Dust From The Left Partition Glass (Despeckle)
Useful transmission functions 6.13 Faxing by reducing the effect of dust from the left partition glass (Despeckle) About the Despeckle Function that reduces the effect that the dust from the left partition glass has on the scan data when scanning an original from the ADF.
Page 151: Sending A Fax After Cancelling Ecm Mode (Ecm Off)
Useful transmission functions 6.14 Sending a fax after cancelling ECM mode (ECM OFF) ECM OFF ECM OFF is a function to send a fax after cancelling the ECM mode and shortening the communication time. ECM mode is provided for communication of error resending method decided by ITU-T (International Telecommunication Union).
Page 152 Useful transmission functions – When fax multi line is not installed When fax multi line is installed Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen. Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings"...
Page 153: Sending A Fax After Cancelling Super G3 Mode (V. 34 Off)
Useful transmission functions 6.15 Sending a fax after cancelling Super G3 mode (V. 34 OFF) V. 34 OFF V. 34 is communication method used during Super G3 fax communication. When the recipient’s machine or this machine is connected through a private switchboard, communication with Super G3 mode may not be possible depending on the setup of the telephone line.
Page 154 Useful transmission functions When fax multi line is not installed When fax multi line is installed Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen. Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings"...
Page 155: Sending An Original In Public/Personal/Group Box By Fax
Useful transmission functions 6.16 Sending an original in Public/Personal/Group box by fax An original saved in Public/Personal/Group box can be sent by fax. Bind and send multiple originals saved in the box when they are to be sent by fax as a single job. Detail When an Personal box is logged in with user authentication, Group box can be used by logging in with account authentication.
Page 156 Useful transmission functions Select the original that is to be faxed and touch [Send]. Specify the destination. – For details on destination, refer to "Specifying only one destination" on page 2-13 and "Specifying multiple destinations (Sequential broadcast transmission or broadcast transmission)" on page 2-22. Touch [Execute].
Page 157: Check The Recipient's Machine And Send The Fax (Check Dest. & Send)
Useful transmission functions 6.17 Check the recipient’s machine and send the fax (Check Dest. & Send) Check Dest. & Send Compares the specified fax number and recipient’s fax number information (CSI) and faxes only if they match. If they do not match there is a communication error and misdirected transmission is prevented. Detail Destination confirmed transmission can also be set at the time of Address Book registration.
Page 158 Useful transmission functions When fax multi line is installed Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen. Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings"...
Page 159: Sending The Fax After Reconfirming The Destination (Destination Check Display Function)
Useful transmission functions 6.18 Sending the fax after reconfirming the destination (Destination Check Display Function) Destination Check Display Function After pressing [Start] key on completion of destination specification, the destination list screen is displayed with the number of destinations. As the fax is sent after reconfirming the destination, misdirected transmission due to the mistake in the destination can be prevented.
Page 160: Sending The Fax After Specifying The Telephone Line (Select Line Settings)
Useful transmission functions 6.19 Sending the fax after specifying the telephone line (Select Line settings) Select Line settings When the fax multi line is installed, transmission is possible after specifying [Line 1] or [Line 2]. Note Fax multi line must be installed. Line cannot be specified when "Line 2 Settings"...
Page 161 Useful transmission functions Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen. Set other functions if required. – For details on Scan Settings, refer to "Specifying scanning conditions" on page 2-9 or "Scan Settings" on page 6-2. –...
Page 162: Sending The Fax With The Password (Password Tx)
Useful transmission functions 6.20 Sending the fax with the password (Password TX) Password TX Password TX is a function for sending the fax with a password. If the recipient’s fax machine is set for closed network receptions, the sender must send a password that is same as the recipient’s closed network reception password.
Page 163 Useful transmission functions Enter the password (Maximum 20 digits) with the keypad. – Numbers 0-9 and # and * can be entered for the password. – If an incorrect number has been entered, touch [Delete] and then correct the number. –...
Page 164: Confidential Transmission (F-Code Tx)
Useful transmission functions 6.21 Confidential transmission (F-Code TX) Confidential transmission A confidential transmission is a function to send an original to specific persons using a confidential box. Sending an original to a confidential box on the recipient’s fax machine is called a confidential transmission and receiving an original in this machine’s confidential box is called confidential reception.
Page 165 Useful transmission functions Touch [SUB Address] and enter the confidential box number of the recipient’s fax machine with the keypad. – When communication password is required, press [Password] and enter the communication password. – Up to 20 digits can be entered in the SUB Address and Password. When the recipient’s fax machine is FK-502, enter the confidential box number within 9 digits and the password within 8 digits.
Page 166: Sending The Fax After Specifying The Relay Destination (F-Code Tx)
Useful transmission functions 6.22 Sending the fax after specifying the relay destination (F-Code TX) Relay destination specification The relay request is a function to send the original once to the relay distribution station and from there to the transmission destination. When there are frequent broadcasts to distant recipient destinations, the entire communication cost can be cut down by grouping the relay distribution station and the relay distribution destination according to area.
Page 167 Useful transmission functions Touch [F-Code TX]. Enter the relay box number of the relay station in the [SUB Address] with the keypad. – Up to 20 digits can be entered in the [SUB Address] and [Password]. – Relay password is mandatory. Numbers 0-9 and # and * can be entered in the password. –...
Page 168 Useful transmission functions – Press [Stop] key to stop the original registration. The scanned original is stored in the memory as a scheduled job and transmission is started. C650 6-50...
Page 169: Specifying The Way Of Adding The Transmission Source Information (Fax Header Settings)
Useful transmission functions 6.23 Specifying the way of adding the transmission source information (Fax Header Settings) Fax Header Settings Fax header (transmission source information) can be added for each job at the time of fax transmission. The contents added to original as fax header are registered in [Header Information] of the Utility mode. The method of adding fax header is set in [Header/Footer Position] of the Utility mode.
Page 170 Useful transmission functions – For North American model, [Header Position] of the Utility mode cannot be set to [OFF]. Select the desired sender name from the list to change the sender name. Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen.
Page 171: Useful Reception Functions
Useful reception functions...
Page 172: Using A Confidentially Received Original
Useful reception functions Useful reception functions Using a confidentially received original Confidential reception Confidential communication is a function to transmit and receive originals between specific persons using a confidential box. Sending an original to a confidential box on the recipient’s fax machine is called a confidential transmission and receiving an original in this machine’s confidential box is called confidential reception.
Page 173: Deleting Confidentially Received Originals
Useful reception functions Deleting confidentially received originals Follow the procedure given below to delete originals registered in confidential box. Press [User Box] key to display Box screen. Press [File Document]. Select the box specified as "confidential box" and touch [OK]. –...
Page 174: Handling Originals Received By Memory
Useful reception functions Handling originals received by memory The received original is stored in memory and can be printed if required. This function is called as the Memory RX. Details of the procedure for printing and deleting the received originals when Memory RX is set are given below.
Page 175: Deleting Received Originals
Useful reception functions Deleting received originals Follow the procedure given below to delete received originals stored in memory. Touch [File Document]. Touch [System User Box]. Touch [Memory RX User Box] and then touch [OK]. Enter the password and touch [OK]. –...
Page 176: Printing At The Time Of Reception
Useful reception functions Printing at the time of reception When [Duplex Print (RX)] is set to [ON] When [Duplex Print (RX)] in Utility mode is set to [ON] the fax is printed on both sides of the paper. 00 /09/ 0 09:38 #00 P.001 P.00 09:38 /09/...
Page 177: Polling
Polling...
Page 178: Sending A Fax When Requested By The Recipient (Polling Transmission)
Polling Polling Sending a fax when requested by the recipient (Polling transmission) Polling transmission is a function that sends originals previously stored in the machine’s memory when requested by the recipient. The original specified for polling transmission is stored in the Polling TX User Box of the System User Box and is sent when a polling request is received from the recipient.
Page 179 Polling Touch [Polling TX]. Touch [Normal]. – Touch [No] to cancel the settings. Touch [OK]. Returns to the Communication Method Settings screen. Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen. Set other functions if required. –...
Page 180: Printing Originals In The Polling Tx User Box
Polling Printing originals in the Polling TX User Box Originals in the Polling TX User Box can be printed. Press [User Box] key to display Box screen. Touch [Use Document]. Touch [System User Box]. Touch [Polling TX User Box] and then touch [OK]. Touch [Start] or press [Start] key.
Page 181 Polling Detail For details on the other original arrangement operations, refer to the User’s Guide [Box Operations]. C650...
Page 182: Receiving A Sender's Original When Requested By This Machine (Polling Reception)
Polling Receiving a sender’s original when requested by this machine (Polling reception) Polling reception Polling reception is a function that sends an original loaded on the sender’s fax machine or an original reserved for polling transmission when requested by the recipient. This function is useful when the telephone bill is to be incurred by the recipient.
Page 183 Polling Touch [Normal]. – Touch [No] to cancel the settings. Touch [OK]. Returns to the Communication Method Settings screen. Touch [OK]. Returns to Communication Settings screen. Touch [Close]. Returns to Fax/Scan screen. Specify the destination. – For details on destination, refer to "Specifying only one destination" on page 2-13 and "Specifying multiple destinations (Sequential broadcast transmission or broadcast transmission)"...
Page 184: Polling After Specifying The Original (Bulletin Board)
Polling Polling after specifying the original (Bulletin board) In this machine, the original that is to be browsed can be posted and original that is to be polling transmitted can be stored by registering the bulletin board. The procedures to register originals on a bulletin board and to receive originals registered on the bulletin board of the sender’s machine by polling are explained below.
Page 185: Printing A Bulletin Board Original
Polling Touch [Bulletin], and enter the box number of the Bulletin Board User Box on which the original is to be registered with the keypad. – Enter a 9 digit number from1 - 999999999 for the box number. Enter ‘5’, if the box number is "000000005".
Page 186: Deleting A Bulletin Board Original
Polling Touch [Bulletin Board User Box] and then touch [OK]. Select the box with the document that is to be printed and touch [OK]. Touch [Start] or press [Start] key. The bulletin board original is printed. Deleting a bulletin board original Follow the procedure given below to delete originals registered in Bulletin Board User Box.
Page 187: Polling Reception Of Bulletin Board Original
Polling Touch [Bulletin Board User Box] and then touch [OK]. Select the box with the original that is to be deleted and touch [OK]. Touch [Delete]. – Touch [Close] to discontinue the operation. Touch [Yes] on the displayed confirmation screen and then touch [OK]. –...
Page 188 Polling Touch [Polling Reception]. Touch [Bulletin] and enter the bulletin board number with the keypad. – A maximum of 20 digits can be entered in the [Bulletin]. – If an incorrect number has been entered, touch [Delete] and then correct the number. –...
Page 189: Registering/Specifying Settings
Registering/Specifying Settings...
Page 190: Displaying The Fax Registration Screen
Registering/Specifying Settings Registering/Specifying Settings Displaying the fax registration screen Displaying Create One-Touch Destination screen Follow the procedure given below to display the Create One-Touch Destination screen. Detail Fax can be registered in PageScope Web Connection. PageScope Web Connection is a device management utility provided by the HTTP server that is embedded in the device.
Page 191: Registering The Address Book
Registering/Specifying Settings Registering the Address Book E-mail addresses, fax numbers of the destinations to which fax is sent frequently and registered boxes can be registered in Address Book. The registered Address Book can be used from [From Address Book] tab of Fax/Scan screen.
Page 192 Registering/Specifying Settings Touch [Fax]. Touch [New]. Touch [Name], enter the destination name and then touch [OK]. – Name of up to 24 characters can be registered. – For details on character input operations, refer to "Entering text" on page 12-3. –...
Page 193 Registering/Specifying Settings – Numbers of up to 38 digits can be entered. – If there is a wrong entry, delete 1 character at a time by touching [Delete] or delete all by pressing [C] (clear) key and correct the entry. –...
Page 194: Registering Fax Numbers In Address Book From Destination Settings Screen
Registering/Specifying Settings Registering fax numbers in Address Book from Destination Settings screen Destinations specified by direct input or destinations specified from direct input sending log can be registered in Address Book. Specify the destination by direct input or from the job history. –...
Page 195 Registering/Specifying Settings – Name of up to 24 characters can be registered. – For details on text input operations, refer to "Entering text" on page 12-3. Register the search character and touch [OK]. – Touch the search button of the search character that is to be registered from [Favorite] - [etc]. –...
Page 196: Changing The Address Book
Registering/Specifying Settings – Returns to the [direct input] tab of the Fax/Scan screen in case of destination registration from direct input and returns to [Job History] tab of the Fax/Scan screen in case of destination registration from Record. Changing the Address Book Follow the procedure given below to change the Address Book.
Page 197: Deleting Address Book Destinations
Registering/Specifying Settings Deleting Address Book destinations Follow the procedure given below to delete destination from the Address Book. If a destination is deleted, it is also deleted from the Group destinations and Program destinations that are using the deleted destination. Display Create One-Touch Destination screen.
Page 198: Registering Group Destinations
Registering/Specifying Settings Registering Group destinations Multiple destinations can be grouped and registered in Group destinations. Group destinations are useful when same contents are to be used in broadcast transmission or at the time of broadcast polling reception. Up to 100 Group destinations (01 - 99, 00) can be registered including the groups used in scanner functions. Up to 500 destinations in the Address Book can be registered in one Group destination.
Page 199 Registering/Specifying Settings Touch [New]. Touch [Name], enter the name of Group destination and touch [OK]. – Name of up to 24 characters can be registered. – For details on text input operation, refer to "Entering text" on page 12-3. Touch [Select Group]. –...
Page 200: Changing Group Destinations
Registering/Specifying Settings Touch [Icon], select the desired icon, and then touch [OK]. – The icons are used in the Image Panel function. Image Panel function can be operated when the optional i-Option LK-101 or i-Option LK-103 is installed. Touch [OK]. –...
Page 201: Deleting Registered Group Destinations
Registering/Specifying Settings Select the group destination to be changed and touch [Edit]. – Touch [↓] or [↑] to go to next page or previous page. – The destination registered in Group destination can be confirmed by selecting the Group destination and touching [Check Job Set].
Page 202: Registering Program Destinations
Registering/Specifying Settings Registering Program destinations Scan Settings, Original Settings, Communication Settings can be combined with frequent transmission destinations and registered in program destinations. If these are registered in program destinations, the functions such as Scan Settings, Original Settings, Communication Settings and registered destinations can be called, specified and transmitted by just touching the program button.
Page 203 Registering/Specifying Settings – Select the page button on the Page List screen, touch [Change Page Name] and change the displayed page name. Select the page button for which program destination is to be registered, and touch [OK]. – Touch [↓] or [↑] to go to next or previous page list. Touch an unregistered button and then touch [Register Program].
Page 204 Registering/Specifying Settings – For details text input operation, refer to "Entering text" on page 12-3. Touch [Address]. Touch [Select from Address Book] or [Direct Input], and enter the destination. – When [Select from Address Book] is touched, select and set the destination from Address Book or Group destinations.
Page 205: Deleting Program Destinations
Registering/Specifying Settings – [Registration Number]: Numbers used for registration are displayed after every 100 registrations. The destinations in the Address Book are displayed on touching the number button applicable to the registered destination. Touch [→] or [←] to scroll the displayed number button. Touch [Close].
Page 206 Registering/Specifying Settings Select the button of the page with the Program destination to be deleted, and then touch [OK]. Select the button of the Program to be deleted and touch [Delete]. – Touch [↓] or [↑] to go to next or previous program destination on the page. –...
Page 207: Changing The Destination Level (Apply Levels/Groups To Destinations)
Registering/Specifying Settings Changing the destination level (Apply Levels/Groups to Destinations) Apply Levels/Groups to Destinations This function is used for information security to specify specific destination information so that only a specific person can access. It can be used in conjunction with user authentication and information on the destination level that matches the specified user level can be accessed.
Page 208 Registering/Specifying Settings Touch [Limiting Access to Destinations]. Touch [Apply Levels/Groups to Destinations]. Touch the destination button whose level is to be changed. Select the destination whose level is to be changed from the list and touch [Apply Level]. – Touch the search button of the search character on the Address Book screen to display the registered destination.
Page 209 Registering/Specifying Settings Change the level and touch [OK]. – Touch [Cancel] to discontinue the change. Destination level is changed. Touch [Close] until it returns to Fax/Scan screen. C650 9-21...
Page 210: Confidential Box Settings
Registering/Specifying Settings Confidential box settings The confidential communication that uses F-code can be used in this machine. It is necessary to register the confidential box for confidential reception. A maximum of 20 confidential boxes can be registered. Note Give the box number and communication password set in the confidential box to the sender. Detail For details on confidential communication operations, refer to "Confidential transmission (F-Code TX)"...
Page 211 Registering/Specifying Settings Touch [Create User Box]. Touch [Public/Personal User Box]. Touch [New]. C650 9-23...
Page 212 Registering/Specifying Settings Specify the [User Box No.], [User Box Name], and [Password]. – For details on [Index] and "Type", refer to the User’s Guide [Box Operations]. – To change the user box number, touch [User Box No.], and then use the keypad to type in a number. If a destination is already registered with the entered number, an error message appears and the destination cannot be registered with the entered number.
Page 213: Working Of Confidential Communication
Registering/Specifying Settings – Confidential reception is possible even if the communication password is not set. In that case, inform only the box number to the sender. To confirm, enter the communication password again and touch [OK]. Touch [OK]. – Touch [Cancel] to discontinue the registration. The box is registered.
Page 214: Specifying Bulletin Board Settings
Registering/Specifying Settings Specifying bulletin board settings Bulletin board polling transmission/reception that uses F-code, can be used in this machine. The Bulletin Board User Box should be set to use bulletin board. Maximum 10 Bulletin Board User Boxes can be registered. Note Notify the set details to the recipient of the bulletin board box.
Page 215 Registering/Specifying Settings Touch [Bulletin Board User Box]. Touch [New]. Specify [User Box No.], [User Box Name], [Password], and then touch [Forward]. – Name of up to 20 characters can be registered. – Password of up to 8 alphanumeric characters can be registered. –...
Page 216: Structure Of Bulletin Board Polling Transmission And Reception
Registering/Specifying Settings Set "Auto Document Delete Time". Touch [OK]. – Touch [Cancel] to discontinue the registration. The box is registered. Touch [Close]. – Returns to procedure 5 when the registration is to be continued. Touch [Close] until it returns to Fax/Scan screen. Structure of Bulletin board polling transmission and reception In bulletin board polling transmission and reception, each fax machine operates with the following role.
Page 217: Specifying Relay Box Settings
Registering/Specifying Settings Specifying Relay box settings Relay broadcast function that uses F-code can be used in this machine. The [Relay RX] of the Utility mode should be set to [ON] and the Relay User Box should be registered for using this machine as intermediate relay station.
Page 218 Registering/Specifying Settings Touch [Relay User Box]. Touch [New]. – For details on Relay RX settings, refer to "Specifying the ON/OFF settings of the function (Function ON/OFF Setting)" on page 10-48. – For details on operation for sending a fax by specifying relay destination, refer to "Sending the fax after specifying the relay destination (F-Code TX)"...
Page 219: Working Of Relay Distribution
Registering/Specifying Settings – Touch [Cancel] to discontinue the registration. Touch [OK]. The box is registered. Touch [Close]. – Returns to procedure 5 when the registration is to be continued. Touch [Close] until it returns to Fax/Scan screen. Working of relay distribution In relay distribution, each fax machine operates with the following roles.
Page 220: Setting Memory Rx User Box
Registering/Specifying Settings Setting Memory RX User Box The received original is saved in Memory RX Box, when [Memory RX Setting] are valid in Utility mode. Detail For details on method of printing original received in Memory RX function, refer to "Handling originals received by memory"...
Page 221: Utility Mode
Utility mode...
Page 222: Utility Mode Operation
Utility mode Utility mode 10.1 Utility mode operation Settings related to the control of this machine are provided in the Utility mode. It is recommended that an administrator should be appointed in advance to manage this machine in order to avoid confusion. The method for displaying and exiting [User Settings] and [Administrator Settings] screens from the Utility mode is explained below.
Page 223: Displaying Administrator Settings Screen
Utility mode Displaying Administrator Settings screen Press [Utility/Counter] key to display the Utility mode screen. Touch [Administrator Settings]. Enter the administrator password and then touch [OK]. – Administrator password can be changed in the [Security Settings]. Administrator should responsibly maintain the password. Terminating Administrator Settings screen Touch [Close] until it returns to Fax/Scan screen.
Page 224: Utility Mode List
Utility mode 10.2 Utility mode list Following settings are provided in the utility operations related to Fax. * is a default value at the time of procurement. User Settings > Custom Display Settings > Scan/Fax Settings Initial Fax/Scan screen settings are specified. (page 10-13) Item Description Values that can be set...
Page 225: User Settings > Scan/Fax Settings > Default Scan/Fax Settings
Utility mode User Settings > Scan/Fax Settings > Default Scan/Fax Settings Set the initial values of Fax/Scan screen. (page 10-19) Item Description Values that can be set Default Scan/Fax Settings Set the initial values of Fax/Scan func- Current Setting/Factory Default* tions.
Page 226: Administrator Settings > System Settings > Stamp Settings
Utility mode Administrator Settings > System Settings > Stamp Settings This setting is specified to use the Annotation function and Stamp/Page Printing function. (page 10-31) Item Description Values that can be set Fax TX Settings This setting is specified to use the Anno- Cancel*/Do Not Cancel tation function and Stamp/Page Printing function.
Page 227: Administrator Settings > Fax Settings > Tx/Rx Settings
Utility mode Item Description Values that can be set Number of RX Call Rings The frequency of pseudo ring-back 0-15 times (2 times*) tones from reception of incoming call till actual reception is set. Number of Redials Number of redials are set when recipi- European models: 0-7 times (3 times*) ent is not responding as line is busy etc.
Page 228: Administrator Settings > Fax Settings > Function Settings > Function On/Off Setting
Utility mode Administrator Settings > Fax Settings > Function Settings > Function ON/OFF Setting ON/OFF settings of the function for transmission or reception are specified. (page 10-48) Item Description Values that can be set Function F-Code TX Set whether or not to use the F-code ON*/OFF ON/OFF Set- transmission function.
Page 229: Administrator Settings > Fax Settings > Function Settings > Forward Tx Setting
Utility mode Administrator Settings > Fax Settings > Function Settings > Forward TX Setting Set whether or not to use the Forwarding fax function. (page 10-55) Item Description Values that can be set Forward TX Setting Set whether or not to use the Forward TX Set- Yes/No* ting.
Page 230: Administrator Settings > Fax Settings > Pbx Connection Setting
Utility mode Administrator Settings > Fax Settings > PBX Connection Setting The connection procedure of PBX telephone line is set. (page 10-67) Item Description Values that can be set PBX Connection Setting This machine is valid when connected to (Outside line number setting) / No* PBX telephone line.
Page 231: Administrator Settings > Fax Settings > Multi Line Settings > Line Parameter Setting
Utility mode Administrator Settings > Fax Settings > Multi Line Settings > Line Parameter Setting Parameters for extended telephone line are set. (page 10-72) Item Description Values that can be set Dialing Method Sets dial methods of line 2 (extended European models: PB telephone lines) North American models: PB*/10pps...
Page 232: Administrator Settings > Security Settings > Security Details > Hide Personal Information
Utility mode Administrator Settings > Security Settings > Security Details > Hide Personal Information Whether or not the destination of the record list of Job List screen is displayed is set. (page 10-84) Item Description Values that can be set Hide Personal Information Whether or not the destination of the ON/OFF*...
Page 233: Setting The Initial State Of Fax/Scan Screen (Scan/Fax Settings)
Utility mode 10.3 Setting the initial state of Fax/Scan screen (Scan/Fax Settings) Initial Fax/Scan screen settings are specified. The selected item here is displayed as initial value. Default Tab: Address Search (LDAP)/Job History/Address Book*/Input Address Initial values of destination column display of Fax/Scan screen are set. Program Default: Temporary One-Touch/PAGE 1*- PAGE 34 Initial values of page display of Fax/Scan program calling screen are set.
Page 234 Utility mode Touch [Scan/Fax Settings]. Select the items to be set. Touch the button for the item to be set, from the displayed items. – Two shortcut keys can be programmed. If optional image controller IC-409 has been installed, only one shortcut key can be programmed.
Page 235: Setting The Screen During Fax Operation (Fax Active Screen)
Utility mode 10.4 Setting the screen during fax operation (FAX Active Screen) Whether or not to display messages of "Sending", "Receiving" on the screen is set. TX Display : Yes/No* Set whether or not to display the message "Sending" on the screen. RX Display : Yes/No* Set whether or not to display the message "Receiving"...
Page 236 Utility mode Select [TX Display] or [RX Display]. Touch [Yes] or [No]. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-16...
Page 237: Specifying Differentiation Of Uppercase/Lowercase Letters When Searching Destinations (Search Option Settings)
Utility mode 10.5 Specifying differentiation of uppercase/lowercase letters when searching destinations (Search Option Settings) Select whether or not to differentiate between uppercase and lowercase letters when searching destinations, and whether or not to display the Search Option screen. Uppercase and Lowercase Letters: Differentiate* / Do Not Differentiate –...
Page 238 Utility mode Specify the search option settings. Touch [OK]. The settings are changed. Continue touching [Close] until the Fax/Scan screen is displayed. C650 10-18...
Page 239: Setting Initial Setting Value Of Fax Function (Default Scan/Fax Setting)
Utility mode 10.6 Setting initial setting value of fax function (Default Scan/Fax Setting) Initial setting value of Fax/Scan function can be set. Fax/Scan function selected when main power supply is turned on or [Reset] key is pressed, can be set. Default Scan/Fax Settings: Current Setting/Factory Default* [Current Setting] Each item set on the touch panel is registered as initial setting of Fax/Scan function before entering on...
Page 240 Utility mode Touch [Current Setting] or [Factory Default] and touch [OK]. The settings are changed. Touch [OK]. Touch [Close] until it returns to Fax/Scan screen. C650 10-20...
Page 241: Specifying The Power Save Transition Conditions (Enter Power Save Mode)
Utility mode 10.7 Specifying the power save transition conditions (Enter Power Save Mode) The settings for shifting to power saving state are set. Enter Power Save Mode: Normal/Immediately* When a fax is received in power save mode, settings about whether to shift to the power save mode after a fixed period of time and after the completion of print (normal state) or to shift to power save mode immediately (instant) are made.
Page 242 Utility mode Touch [Enter Power Save Mode]. Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-22...
Page 243: Setting The Printing Method For Received Original (Print/Fax Output Settings)
Utility mode 10.8 Setting the printing method for received original (Print/Fax Output Settings) The printing method for received original is set. Fax: Batch Print*/Page Print The printing method for received original is set. * is a default value at the time of procurement. Specifying Print/Fax Output Settings Display the Administrator Settings screen as described in "Displaying Administrator Settings screen"...
Page 244 Utility mode Touch [Print/Fax Output Settings]. Touch [Fax]. Select the printing method. – [Batch Print] The printing starts after receiving all received originals. – [Page Print] The printing starts when 1 page of received original is received. – When [Duplex Print (RX)] is [ON], the printing starts after receiving the data of both sides (2 pages). Touch [OK].
Page 245: Specifying The Prohibitions To Cause A Change In Destination Registration (Registering And Changing Addresses)
Utility mode 10.9 Specifying the prohibitions to cause a change in destination registration (Registering and Changing Addresses) Whether or not to prohibit changes in the registered destination of Fax is set. Registering and Changing Addresses: Allow*/Restrict * is a default value at the time of procurement. Specifying settings for Registering and Changing Addresses Display the Administrator Settings screen as described in "Displaying Administrator Settings screen"...
Page 246 Utility mode Touch [Restrict Access to Job Settings]. Touch [Registering and Changing Addresses] and then touch [Restrict]. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-26...
Page 247: Setting Prohibitions For Sending A Fax To Multiple Destinations (Restrict Broadcasting)
Utility mode 10.10 Setting prohibitions for sending a fax to multiple destinations (Restrict Broadcasting) Whether or not to prohibit sending a fax to multiple destinations is set. Restrict Broadcasting: ON/OFF* * is a default value at the time of procurement. Setting prohibitions for sending a fax to multiple destinations Display the Administrator Settings screen as described in "Displaying Administrator Settings screen"...
Page 248 Utility mode Touch [Restrict Operation]. Touch [Restrict Broadcasting] and then touch [ON]. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-28...
Page 249: Specifying Whether To Reset The Destination And Settings (Reset Data After Job)
Utility mode 10.11 Specifying whether to reset the destination and settings (Reset Data After Job) Select whether the settings are reset to their defaults or whether they remain for the next fax. Reset Data After Job: Reset All*/Reset Destination Only /Confirm with User Reset Destination Only: Select this setting to retain the settings and reset only the destination.
Page 250 Utility mode Touch [Job Reset]. Touch [Next Job]. Touch [Reset Data After Job], and then touch [Reset Destination Only] or [Confirm with User]. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-30...
Page 251: Specifying Stamp Printing Specifications (Stamp Settings)
Utility mode 10.12 Specifying stamp printing specifications (Stamp Settings) This setting is specified to use the Annotation function and Stamp/Composition functions at the time of fax transmission. Fax TX Settings: Cancel*/ Do Not Cancel Cancel: The fax transmission source is sent without the stamp setting applied. Do Not Cancel: The fax transmission source is sent with the stamp setting applied.
Page 252 Utility mode Touch [Stamp Settings]. Touch [Fax TX Settings]. Touch [Do Not Cancel]. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-32...
Page 253: Protecting The Destination Information (Limiting Access To Destinations)
Utility mode 10.13 Protecting the destination information (Limiting Access to Destinations) The destination level that protects destination information is set. Create Group: 1-20 Groups used in the destination level settings are registered. Apply Levels/Groups to Destinations: Level 0* to Level 5, reference allowed group Address Book, Group destination and destination level of Program are set.
Page 254 Utility mode Touch [Create Group]. Touch an unregistered group button. – Details of the group button can be checked after touching registered group button and then touching [Details]. Touch [Edit]. Touch [Group Name]. C650 10-34...
Page 255: Specifying Destination Level Settings
Utility mode Input group name and touch [OK]. Select "Access Allowed Level". Touch [OK]. Groups are registered. Touch [OK]. – Returns to procedure 5 when the registration is to be continued. Touch [Close] until it returns to Fax/Scan screen. Specifying destination level settings Address Book, Group destination and destination level of Program are set.
Page 256 Utility mode Touch [Limiting Access to Destinations]. Touch [Apply Levels/Groups to Destinations]. Select the Destination type whose destination level is to be set. C650 10-36...
Page 257 Utility mode Select the destination whose destination level is to be set from the list. Set the destination level. – When setting destination level registered by the [Create Group] as a group, touch [Apply Group] and touch group button and then touch [OK]. –...
Page 258: Registering Transmission Source Name And Fax Number (Header Information)
Utility mode 10.14 Registering transmission source name and fax number (Header Information) Sender name and fax number are registered. Sender: Within 30 characters. Multiple sender names can be registered to be output to the documents sent to the receiver as sender information.
Page 259 Utility mode Touch [Sender]. Select the list that is to be registered, touch [New], enter Sender name and then touch [OK]. – Touch [↓] or [↑] to go to next page or previous page. – Touch [Edit] when already registered sender name are to be corrected. –...
Page 260 Utility mode Enter fax number using keypad, [+], [Space], [←], [→], and touch [OK]. – To delete all entered characters, press [C] (clear) key on the control panel. – [+]: + is entered. – [Space]: Space is entered. – [←]: Moves the cursor to the left. –...
Page 261: Specifying The Method Of Setting The Transmission Source/Reception Information (Header/Footer Position)
Utility mode 10.15 Specifying the method of setting the transmission source/reception information (Header/Footer Position) The location where Header and Footer is added is specified. The location where Header and Footer is added is of following type respectively. Header Position Inside Body Text: Transmission source information is written on the original and then printed. Outside Body Text*: Transmission source information is printed on the outer side of the original.
Page 262 Utility mode Touch [Header/Footer Position]. Select the items to be set. Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-42...
Page 263: Specifying Transmission/Receiving Mode (Line Parameter Settings)
Utility mode 10.16 Specifying transmission/receiving mode (Line Parameter Settings) The items related to transmission and reception is specified. Dialing Method: European models: PB North American models: PB*/10pps The dialing method is specified Receive Mode: Auto RX*/Manual RX In case of automatic reception, select the Auto RX settings and if the line is often busy due to external phone connection etc., select the Manual RX settings.
Page 264 Utility mode Touch [Line Parameter Settings]. Select the items to be set. – Touch [↓] or [↑] to display the next or the previous page. Touch the button for the item to be set, from the displayed items. – To change the [Line Monitor Sound Vol.] touch the [Line Monitor Sound Vol.] and set the level after touching [Lower] or [Higher] and then touch [OK].
Page 265: Settings Of Transmission And Reception Mode (Tx/Rx Settings)
Utility mode 10.17 Settings of transmission and reception mode (TX/RX Settings) Handling the file at the time of polling transmission or printing methods at the time of reception are set. Duplex Print (RX): ON/OFF* When set to [ON], the received original is printed on both sides of the paper. When [Print Separate Fax Pages] is [ON], it is not displayed.
Page 266 Utility mode Touch [Fax Settings]. – Some items may not be displayed according to setting options. – In the Utility mode, the number displayed on button can be entered and selected on the keypad. For [Fax settings], enter [8] on the keypad. Touch [TX/RX Settings].
Page 267 Utility mode Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-47...
Page 268: Specifying The On/Off Settings Of The Function (Function On/Off Setting)
Utility mode 10.18 Specifying the ON/OFF settings of the function (Function ON/OFF Setting) ON/OFF settings of the function for transmission or reception are specified. F-Code TX: ON*/OFF Set whether or not to use the F-code transmission function. For details on the confidential function, refer to "Confidential transmission (F-Code TX)" on page 6-46. For details on F-Code transmission, refer to "Sending the fax after specifying the relay destination (F- Code TX)"...
Page 269 Utility mode Touch [Function Settings]. Touch [Function ON/OFF Setting]. – If any of these functions like [Memory RX Setting], [Forwarding TX Setting], [PC-FAX RX Setting], [TSI User Box Setting] are valid, the other items are not displayed. Select the items to be set. C650 10-49...
Page 270 Utility mode Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-50...
Page 271: Specifying Memory Reception Settings (Memory Rx Settings)
Utility mode 10.19 Specifying memory reception settings (Memory RX Settings) Whether or not to use the Memory RX function is set. When these settings are valid, password (within 8 digits) used at the time of printing is set. Memory RX is the function of printing the received original after storing in the memory for some time and then printing after the receiving such instruction and not printing it immediately.
Page 272 Utility mode Touch [Memory RX Settings]. Touch [No], confirm that the cursor is displayed on the password input column and then enter the password that is to be input at the time of printing (within 8 digits). Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen.
Page 273: Reception Settings Only For The Specific Caller (Closed Network Rx)
Utility mode 10.20 Reception settings only for the specific caller (Closed Network RX) Whether or not to use the closed network reception function is set. When the function is valid, password that is used in closed network reception should be set within 4 digits. Closed network reception is a function that accepts the communication only from the caller machine that matches the password.
Page 274 Utility mode Touch [Closed Network RX]. Touch [NO] and enter password (numerical character 4 digits) that is used in closed network reception after confirming the display of the cursor in the password input column. – When [C] (clear) key is pressed, all entered contents are deleted. Touch [OK].
Page 275: Forwarding The Received Original (Forward Tx Setting)
Utility mode 10.21 Forwarding the received original (Forward TX Setting) The forwarded fax is set. Forward TX Setting is a function that forwards the received original to other party specified in advance. Forwarded TX Setting: Yes/No* Following setting are made when set to [Yes]. –...
Page 276 Utility mode Touch [Forward TX Setting]. Select [Yes]. Set "Output Method". – [Forward & Print]: The received original is forwarded and this machine prints the original. – [Forward & Print (If TX Fails)]: The received original is forwarded and when it cannot be forwarded, this machine prints the original.
Page 277 Utility mode – When [C] (clear) key is pressed, all entered contents are deleted. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-57...
Page 278: Specifying The Resending (Incomplete Tx Hold)
Utility mode 10.22 Specifying the resending (Incomplete TX Hold) The original, which cannot be sent even by auto redial, is temporality saved in Fax Retransmit User Box since there is communication error or recipient’s line is busy. Resending settings: Yes/No* When it is set to [Yes], the settings are as follows.
Page 279 Utility mode Touch [Incomplete TX Hold]. Touch [Yes] to specify the "File Storage Duration". Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-59...
Page 280: Specifying The Reception In Box Of Hard Disk (Pc-Fax Rx Setting)
Utility mode 10.23 Specifying the reception in box of hard disk (PC-FAX RX Setting) Whether or not to use the PC-FAX RX function is set. When set to [Allow], output destination box is set. PC-FAX RX saves the document file received by fax in the hard disk box. Saved file can be downloaded on network computer.
Page 281 Utility mode – In the Utility mode, the number displayed on button can be entered and selected on the keypad. For [Fax settings], enter [8] on the keypad. Touch [Function Settings]. Touch [PC-FAX RX Setting]. C650 10-61...
Page 282 Utility mode Select the [Allow]. – [Restrict]: PC-FAX is not received – [Allow]: PC-FAX is received even if any of the fax number or PC-FAX number is received and received originals are saved in Specified User Box. Select the box in which original received by PC- FAX is saved by "Receiving User Box Destination". –...
Page 283: Distributing The Received Original Per Sender (Tsi User Box Setting)
Utility mode 10.24 Distributing the received original per sender (TSI User Box Setting) Whether or not to use the TSI User Box Setting function is set. When it is used, the TSI User Box is registered. The originals received by sender’s fax number (TSI) is transmitted to distribution destination (box destination/ e-mail address/ FTP address/SMB address/WebDAV address) set for each sender.
Page 284 Utility mode – In the Utility mode, the number displayed on button can be entered and selected on the keypad. For [Fax settings], enter [8] on the keypad. Touch [Function Settings]. Touch [TSI User Box Setting]. C650 10-64...
Page 285 Utility mode Touch [Yes], to set the TSI User Box Setting. Select the operation when unregistered TSI information is received in "Action when TSI User Box is not set". – [Automatically Print] Received original is printed. – [Memory RX User Box] Received original is saved in Memory RX User Box.
Page 286 Utility mode Enter the transmission source information (fax number) of transmission source using numeric keypad, [+], [Space], [←] or [→]. – [+]: + is entered. – [Space]: Space is entered. – [←]: Moves the cursor to the left. – [→]:Moves the cursor to the right. –...
Page 287: Specifying The Function Related To Private Branch Exchange (Pbx Connection Setting)
Utility mode 10.25 Specifying the function related to private branch exchange (PBX Connection Setting) The connection methods of PBX telephone lines are set. PBX Connection Setting: (Outside line number setting)/No* Set outside line number, when PBX connection mode is activated. The outside line number is a number to connect to outside line as 0 of 0 sending.
Page 288 Utility mode Touch [No], enter the outside line number after confirming the display of cursor in input field of outside line number. – When [C] (clear) key is pressed, all entered contents are deleted. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen.
Page 289: Specifying The Printing Methods For Report (Report Setting)
Utility mode 10.26 Specifying the printing methods for report (Report Setting) The printing methods of report are set. Activity Report: ON*/OFF If "ON" is selected, settings can be specified for the following. Output Setting: Daily/Every 100 comm.*/100/daily If "Daily" or "100/daily" is selected, settings can be specified for the following. Output Time Settings: 00:00 to 23:59 (9:00*) Select whether or not to print the Activity Report, and when to print it.
Page 290 Utility mode Touch [Fax Settings]. – Some items may not be displayed according to setting options. – In the Utility mode, the number displayed on button can be entered and selected on the keypad. For [Fax settings], enter [8] on the keypad. Touch [Report Settings].
Page 291 Utility mode Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-71...
Page 292: Specifying The Extended Telephone Line Parameter Settings (Lines Parameter Setting)
Utility mode 10.27 Specifying the extended telephone line parameter settings (Lines Parameter Setting) Parameters for extended telephone line are set. Dialing Method: European models: PB North American models: PB*/10pps Sets dial methods of line 2 (extended telephone lines) Number of RX Call Rings: European models: 0 - 7 times (3 times*) North American models: 0 - 7 times (1 time*) Incoming calls frequency of line 2 (extended telephone lines) is set.
Page 293 Utility mode Touch [Multi Line Settings]. Touch [Line Parameter Setting]. Select the items to be set. Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-73...
Page 294: Specifying The Extended Telephone Line Function Settings (Function Settings)
Utility mode 10.28 Specifying the extended telephone line function settings (Function Settings) Functions for extended telephone line are set. PC-FAX TX Settings: Line 1/Line 2/No Selection* The telephone lines when PC-FAX is sent, are set. * is a default value at the time of procurement. Note Extended telephone lines can be set only when fax multi line is installed.
Page 295 Utility mode Touch [Function Settings]. Select the items to be set. Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-75...
Page 296: Specifying The Communication Methods Of Extended Telephone Lines (Multi Line Settings)
Utility mode 10.29 Specifying the communication methods of Extended telephone lines (Multi Line Settings) The communication function of telephone line 2 (extended telephone line) is set. Multi Line Settings: TX and RX*/RX Only/TX Only The communication function of telephone line 2 (extended telephone line) is set. * is a default value at the time of procurement.
Page 297 Utility mode Touch [Multi Line Settings]. Touch the button for the item to be set, from the displayed items. Touch [OK]. The settings are changed. Touch [Close] until it returns to Fax/Scan screen. C650 10-77...
Page 298: Specifying The Fax Number Of Extended Telephone Line (Sender Fax No.)
Utility mode 10.30 Specifying the fax number of Extended telephone line (Sender Fax No.) The fax number of Extended telephone line is registered. Sender Fax No.: Within 20 characters using 0 - 9, +, space, *, # Registered fax number is printed on the originals received by the recipient as Header information. Note Extended telephone lines can be set only when fax multi line is installed.
Page 299 Utility mode Touch [Sender Fax No.]. Enter the fax number using keypad, [+], [Space], [←], [→]. – [+]: + is entered. – [Space]: Space is entered. – [←]: Moves the cursor to the left. – [→]:Moves the cursor to the right. –...
Page 300: Prohibiting The Direct Input Of Fax Number (Manual Destination Input)
Utility mode 10.31 Prohibiting the direct input of fax number (Manual Destination Input) Set whether direct input of destination and address search are permitted. Manual Destination Input: Allow*/Restrict * is a default value at the time of procurement. Specifying Manual Destination Input settings Display the Administrator Settings screen as described in "Displaying Administrator Settings screen"...
Page 301 Utility mode Touch [Manual Destination Input]. Touch [Restrict]. Touch [OK]. Direct input of fax number and address search are prohibited. Touch [Close] until it returns to Fax/Scan screen. C650 10-81...
Page 302: Prohibiting The Fax Sending Function (Restrict Fax Tx)
Utility mode 10.32 Prohibiting the Fax sending function (Restrict Fax TX) Set whether Fax sending is prohibited or not. If [Restrict Fax TX] is set to [ON], the Fax function is not displayed on the Fax/Scan screen. Restrict Fax TX: ON/OFF* The Fax sending function is prohibited.
Page 303 Utility mode Touch [↓]. Touch [Restrict Fax TX]. Touch [ON]. Touch [OK]. Fax sending function is prohibited. Touch [Close] until it returns to Fax/Scan screen. C650 10-83...
Page 304: Specifying Settings Such That Fax Number Cannot Be Displayed (Hide Personal Information)
Utility mode 10.33 Specifying settings such that fax number cannot be displayed (Hide Personal Information) Whether to display destination of log list on Job List screen is set. Hide Personal Information : ON/OFF* * is a default value at the time of procurement. Specifying the Hide Personal Information settings Display the Administrator Settings screen as described in "Displaying Administrator Settings screen"...
Page 305 Utility mode Touch [↓]. Touch [Hide Personal Information]. Touch [ON]. Touch [OK]. Fax number is hidden. Touch [Close] until it returns to Fax/Scan screen. C650 10-85...
Page 306: Specifying Settings Such That Communication History Cannot Be Displayed (Display Activity Log)
Utility mode 10.34 Specifying settings such that communication history cannot be displayed (Display Activity Log) Whether or not to display activity is set. Display Activity Log: ON*/OFF * is a default value at the time of procurement. Specifying Display Activity Log settings Display the Administrator Settings screen as described in "Displaying Administrator Settings screen"...
Page 307 Utility mode Touch [↓]. Touch [Display Activity Log]. Touch [OFF]. Touch [OK]. Activity log is hidden. Touch [Close] until it returns to Fax/Scan screen. C650 10-87...
Page 308: Reports And Lists
Reports and Lists...
Page 309: Report / List Types
Reports and Lists Reports and Lists 11.1 Report / List Types This machine prints the following types of reports and lists. Reports Reports include automatically printed reports, reports for which printing methods can be set and reports for which printing commands can be given if required. Report Name Description Activity Report...
Page 310: Lists
Reports and Lists Report Name Description Relay Request Report Relay Request Report is printed automatically when [Relay Request Re- port] in the [Report Settings] of the Utility mode is set to [ON]. PC-FAX TX Error Report PC-FAX TX Error Report is printed automatically when a PC-FAX trans- mission error occurs, when [PC-FAX TX Error Report] in the [Report Set- tings] of the Utility mode is set to [ON].
Page 311: Activity Report
Reports and Lists 11.2 Activity Report Conventions of Activity Report Transmission and reception records are described in Activity Report. Maximum 700 communications including transmission and reception are recorded on different pages for transmission and reception respectively. The Activity Report is printed automatically and only transmission records (TX Report), only reception records (RX Report) and transmission and reception records (Activity Report) can also be printed if required.
Page 312: Auto Printing
Reports and Lists Result: Described when communication is terminated normally. S-OK: Described when communication has stopped. PW-OFF: Described when operation power switch was turned OFF during communication. TEL: Described when there is telephone call. Described when there is communication error. Cont: Described when there is a transmission error and that there is transition to resend wait mode (Error page redial).
Page 313: Manual Printing
Reports and Lists Manual Printing Can be printed as follows. Touch [Job List]. Touch [Job Details]. Touch [Send]. Touch [Job History]. – When optional fax multi line is installed, telephone line wise list can be displayed during execution of [Send]. Touch [L1] to display list during execution of Line 1 and touch [L2] to display list during the execution of Line 2.
Page 314 Reports and Lists Touch [Comm. List]. Touch [Fax TX List]. Touch the button for the desired report below "Report Types", select "Output Limit", and then press the [Start] key. – For details on the number of items, refer to "Report / List Types" on page 11-2. Report is printed.
Page 315: Tx Result Report
Reports and Lists 11.3 TX Result Report Conventions of TX Result Report Destination: Any of the following is described. Name registered with the destination in the Address Book or in the program Recipient’s telephone number Start Time: Describes the start time of the communication. Time: Describes the time required for communication.
Page 316: Manual Printing
Reports and Lists CALL Manual communication Forward Binding Position FCODE F-code specifications Relay Bulletin board Manual Printing TX Result Report Check screen is displayed for every transmission when [TX Result Report Check] of the Utility mode is set to [ON]. Transmission report is printed on touching [Yes].
Page 317: Polling Tx Report
Reports and Lists 11.4 Polling TX Report Polling TX Report is printed automatically. ON / If TX Fails / OFF can be set for [TX Result Report] in the Utility mode. Destination: Recipient’s machine ID is described. Start Time: Describes the start time of the communication. Time: Describes the time required for communication.
Page 318 Reports and Lists Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [TX Result Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-11...
Page 319: Polling Rx Report
Reports and Lists 11.5 Polling RX Report Polling RX Report is printed automatically when a polling transmission is received. ON / If TX Fails / OFF can be set for [TX Result Report] in the Utility mode. Destination: Any of the following is described. Destination name for recipients’...
Page 320 Reports and Lists Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [TX Result Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-13...
Page 321: Sequential Polling Rx Report
Reports and Lists 11.6 Sequential Polling RX Report Result of polling to multiple destinations is printed automatically. ON/OFF can be set in [Sequential TX Report] of the Utility mode. Destination: Any of the following is described. Destination name for recipients’ whose destination name is registered in Address Book Recipient’s telephone number Start Time: Describes the start time of the communication.
Page 322 Reports and Lists Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [Sequential TX Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-15...
Page 323: Reservation Communication Report
Reports and Lists 11.7 Reservation Communication Report Report is printed automatically when Timer TX is specified. ON/OFF can be set in [Timer Reservation TX Report] of the Utility mode. Destination: Any of the following is described. Name registered with the destination in the Address Book or in the program Recipient’s telephone number Create Time: Describes the time when the transmission is reserved.
Page 324: Reservation Polling Tx Report
Reports and Lists 11.8 Reservation Polling TX Report Reservation Polling TX Report is printed automatically when a polling transmission is reserved. ON/OFF can be set in [Timer Reservation TX Report] of the Utility mode. Destination: Not described. Create Time: Describes the time when the polling transmission is reserved. Start Time: Not described.
Page 325: Broadcast Reserved Report
Reports and Lists 11.9 Broadcast Reserved Report Broadcast Reserved Report is printed automatically when sequential broadcast transmission is reserved. ON/OFF can be set in [Timer Reservation TX Report] of the Utility mode. Destination: Any of the following is described. Name registered with the destination in the Address Book or in the program Recipient’s telephone number when destination is specified on the keypad Create Time: Describes the time when the transmission is reserved.
Page 326: An Address Polling Rx Reserved Report
Reports and Lists 11.10 An address Polling RX Reserved Report An address Polling RX Reserved Report is printed automatically when polling is reserved for one destination. ON/OFF can be set in [Timer Reservation TX Report] of the Utility mode. Destination: Recipient’s telephone number is described. Create Time: Describes the time when polling is reserved.
Page 327: Sequence Polling Rx Reserved Report
Reports and Lists 11.11 Sequence Polling Rx Reserved Report Sequence Polling Rx Reserved Report is printed automatically when polling is reserved for multiple destinations. ON/OFF can be set in [Timer Reservation TX Report] of the Utility mode. Destination: Recipient’s telephone number is described. Create Time: Describes the time when polling is reserved.
Page 328: Confidential Rx Report
Reports and Lists 11.12 Confidential RX Report Confidential RX Report is printed automatically when there is a confidential reception. ON/OFF can be set in [Confidential RX Report] of the Utility mode. Destination: Any of the following is described. Destination name when destination name is registered in Address Book. Recipient’s telephone number Start Time: Describes the start time of the communication.
Page 329 Reports and Lists Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [Confidential RX Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-22...
Page 330: Bulletin Board Transmission Report (Polling Tx Report)
Reports and Lists 11.13 Bulletin board transmission report (Polling TX Report) Bulletin board reception result report (Polling TX Report) is printed automatically when an original registered on the bulletin board is transmitted through polling. ON/OFF can be set in [Bulletin TX Report] of the Utility mode. Destination: Any of the following is described.
Page 331 Reports and Lists CALL Manual communication Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [Bulletin TX Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-24...
Page 332: Relay Tx Result Report
Reports and Lists 11.14 Relay TX Result Report Relay TX Result Report is printed automatically when there is a relay transmission to a relay distribution destination as intermediate relay station. ON/OFF can be set in [Relay TX Result Report] of the Utility mode. Destination: Any of the following is described.
Page 333 Reports and Lists CALL Manual communication Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [Relay TX Result Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-26...
Page 334: Relay Request Report
Reports and Lists 11.15 Relay Request Report Relay Request Report is printed automatically when an original is received from originating station as intermediate relay station. ON/OFF can be set in [Relay Request Report] of the Utility mode. Destination: Any of the following is described. Destination name when destination name is registered in Address Book.
Page 335 Reports and Lists CALL Manual communication Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [Relay Request Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-28...
Page 336: Pc-Fax Tx Error Report
Reports and Lists 11.16 PC-FAX TX Error Report PC-FAX TX Error Report is printed automatically when there is an error during PC-FAX transmission. ON/OFF can be set in [PC-FAX TX Error Report] of the Utility mode. Destination: Any of the following is described. Destination name for recipients’...
Page 337: Broadcast Report
Reports and Lists 11.17 Broadcast Report Broadcast Report is printed automatically when sequential broadcast transmission is completed. ON/OFF can be set in [Sequential TX Report] of the Utility mode. Report output timing (all destination batches/each destination) can be specified in [Broadcast Result Report]. Destination: Any of the following is described.
Page 338 Reports and Lists Frame Erase transmission CALL Manual communication Forward Binding Position FCODE F-code specifications Relay Bulletin board Detail For details on [Sequential TX Report] and [Broadcast Result Report], refer to "Specifying the printing methods for report (Report Setting)" on page 10-69. C650 11-31...
Page 339: Speed Dial List (Address Book Destination List)
Reports and Lists 11.18 Speed Dial List (Address Book destination list) Speed Dial List (Address Book destination list) can be printed. Conventions of Speed Dial List No.: Registration number. Index: Registered search word. Name: Registered destination name. Dial Number: Registered fax number. Line Settings: * is set when telephone line settings are specified.
Page 340 Reports and Lists Touch [Address Book List]. Set "List Output Number". – Touch [Starting Destination No.] and enter the registration number of Address Book destination that is to be printed on the keypad. – Touch [Number of Destinations] and enter the number of pages that are to be printed from the print start number on the keypad.
Page 341: Group Address List
Reports and Lists 11.19 Group Address List Registered Group Address List can be printed. Conventions of Group Address List No.: Group number Name: Registered Group name. Addr. No.: Address Book destination number registered in the Group. Access Allowed Level: Registered levels that can be referred. Regist Count: Number of Address Book destination numbers registered in the Group.
Page 342 Reports and Lists Touch [Group List]. Set "List Output Number". – Touch [Starting Destination No.] and enter the registration number of Group destination that is to be printed on the keypad. – Touch [Number of Destinations] and enter the number of pages that are to be printed from the print start number on the keypad.
Page 343: Program List
Reports and Lists 11.20 Program List Registered Program List can be printed. Conventions of Program List No.: Program destination number. Name: Program destination registration name. Address Book: Address Book destination No. Printing Program List Press [Utility/Counter] key. Touch [Administrator Settings]. Enter the administrator password and then touch [OK].
Page 344 Reports and Lists Touch [Program List]. Set "Starting Output Number". – Touch [Starting Destination No.] and enter the registration number of Program destination that is to be printed on the keypad. – Touch [Number of Destinations] and enter the number of pages that are to be printed from the print start number on the keypad.
Page 345: Fax Setting List
Reports and Lists 11.21 Fax Setting List List of fax setup values specified in this machine can be printed. Conventions of FAX Settings List Item: Items of the Utility mode. Setting: Setting status. C650 11-38...
Page 346: Conventions Of Relay List
Reports and Lists Conventions of Relay List No.: Relay User Box number. Group No.: Group registered as relay distribution destination. Password: Relay password. C650 11-39...
Page 347: Conventions Of Sender (Tsi) Rx User Box
Reports and Lists Conventions of Sender (TSI) RX User Box No.: Registration number of TSI User Box Settings. Sender (TSI): Registered transmission source information. Forwarding Destination: Specified distribution destination. Conventions of Confidential/Bulletin List No.: Registration number of confidential box Bulletin Board User Box Name: Registered name.
Page 348: Printing Fax Setting List
Reports and Lists Password: Confidential password. Type: "User Box No." (confidential box No.) or "Bulletin" are displayed Printing Fax Setting List Press [Utility/Counter] key. Touch [Administrator Settings]. Enter the administrator password and then touch [OK]. – Administrator password can be changed in the [Security Settings]. Administrator should responsibly maintain the password.
Page 349 Reports and Lists Select the tray that is to be used for printing. Touch [Start] or press [Start] key. – If number of papers required for Report/List are not loaded on the paper tray, [Start] key LED turns red and [Start] key is not accepted. The Fax Setting List is printed.
Page 350: Appendix
Appendix...
Page 351: About The Original Number Stored In The Memory
Appendix Appendix 12.1 About the original number stored in the memory A standard hard disk of 60 GB is installed in this machine and the fax image is saved in 31 GB area in this hard disk. Approximately 10000 pages of originals of standard size paper (A4/Letter with approximately 700 characters), saved/received from each function (copy, print, scan, box, fax) can be stored in the hard disk.
Page 352: Entering Text
Appendix 12.2 Entering text The following procedure describes how to use the keyboard that appears in the touch panel for typing in the names of registered users and custom paper sizes. The keypad can also be used to type in numbers. Any of the following keyboards may appear.
Page 353: Enlarging The Keyboard
Appendix Touching [Shift] switches the keyboard display between lowercase letters (numbers) and uppercase letters (symbols). Enlarging the keyboard The keyboard can be displayed larger so that it easier to read. While the keyboard is displayed, touch [Enlarge ON]. The keyboard is displayed enlarged. To cancel the enlarged display and return the keyboard to its normal size, touch [Enlarge OFF] while the keyboard is displayed enlarged.
Page 354: To Type Text
Appendix To type text Touch the button for the desired character from the keyboard that appeared. – To type in uppercase letters or symbols, touch [Shift]. – Numbers can also be typed in with the keypad. The entered characters appear in the text box. Note To revert to the setting when the keyboard was displayed, touch [Cancel].
Page 355: Fax Glossary
Appendix 12.3 Fax glossary The glossary explains the terms generally used for fax transmission. The terms of the functions that are not stored for this machine are also explained. Terms Explanation This is an abbreviation of bit per second. It means the amount of data sent in 1 second as the unit of data transmission. (Error Correction Mode: Error correction mode) Error resend mode of G3 communication.
Page 356 Appendix Terms Explanation Main scanning di- This is the horizontal direction for scanning originals. rection Default value The setting value specified in advance when the machine was shipped from the factory. Some default settings can be changed from the Utility mode. It is convenient when frequently used value is set as default settings depending on the usage conditions.
Page 357 Appendix Terms Explanation Pause A temporary break in dialing. In this machine, each pause creates a one second break during dialing. Polling This is a function for sending an original loaded on the machine or stored in the memory when requested by the recipient.
Page 358: Index
Index...
Page 359 Index Index Numerics 1-Sided ..............2-10 FAX Active Screen ..........10-15 2-Sided ..............2-42 Fax cannot be received .........3-5 Fax cannot be sent ........2-31 Fax Header Settings ......2-50 6-51 10-38 Aborting ...............2-36 Fax Setting List ..........11-38 Activity Report .............11-4 Footer Setting ............3-13 Address Book ............9-3 Forwarding TX Setting ........10-55 Address Type ............2-14 Frame Erase ............6-10...
Page 360 Index Original Settings ............6-3 Simplex/Duplex ...........2-10 Original type ............2-9 Specifications ............5-2 Overseas TX ............2-48 Specified User Box ..........1-11 Specifying the scan conditions ......2-9 Speed Dial List ...........11-32 Password TX ............6-44 Stamp Settings ..........10-31 PBX Connection Setting ........10-67 Stamp/Composition ..........6-3 PC-FAX RX function ..........1-11 System User Box ..........1-11 PC-FAX RX Setting ..........10-60 PC-FAX TX Error Report ........11-29...

Konica Minolta bizhub C650 User Manual

Introduction

Special Notice to User

Send a Fax (Faxing

Available Features

Explanation of Manual Conventions

Descriptions of Original Documents and Paper

User's Guides

1 Before Using this Machine

2 To Send a Fax

3 Reception

4 Troubleshooting

5 Specifications

6 Useful Transmission Functions

7 Useful Reception Functions

8 Polling

9 Registering/Specifying Settings

10 Utility Mode

Quick Links

Related Manuals for Konica Minolta bizhub C650

Summary of Contents for Konica Minolta bizhub C650
