2.

LUBRICATION

Apply the specified lubricants to the lubrication points as shown below.
Lubricant type
(Manufacturer
Molykote grease
EM-30L
(Dow Corning)
Molykote grease
EMD-110
(Dow Corning.)
Molykote grease
PG662
(Dow Corning)
[ 1 ]

Document feed roller ASSY and document ejection roller ASSY

)
Half of a rice-sized
pinch of grease
3
(3 mm )
–––––––
–––––––
Lubricant amount
Rice-sized pinch Two rice-sized pinches
3
of grease (6 mm ) of grease (12 mm
IV - 65
Five rice-sized pinches
3
) of grease (30 mm
––––––– –––––––
––––––– –––––––
3
)
