2.

MECHANISMS

The facsimile equipment is classified into the following mechanisms:
n SCANNER MECHANISM
n LASER PRINTING MECHANISM
n SENSORS AND ACTUATORS
- Document feeding and ejecting mechanism
- Document scanning mechanism
- Paper pick-up and registration mechanism
- Print process mechanism (consisting of charging,
exposing, developing, and transferring processes) with
paper feeding mechanism
- Heat-fixing mechanism with paper feeding mechanism
- Paper ejecting mechanism
