3.6.3

Onboard Device Configuration

Onboard Devices Configuration
HDA Controller
Front Panel Type
Realtek LAN
LAN Boot ROM
Onboard 1394 Controller
J-Micron eSATA/PATA Controller [IDE Mode]
Serial Port1 Address
HDA Controller [Enabled]
[Enabled] Enables the High Definition Audio Controller.
[Disabled] Disables the controller.
Front Panel Type [HD Audio]
[AC97] Set the front panel audio connector (AAFP) mode to legacy AC'97
[HD Audio] Set the front panel audio connector (AAFP) mode to high-definition audio.
Realtek LAN [Enabled]
[Enabled] Enables Realtek LAN Controller.
[Disabled] Disables Realtek LAN Controller.
LAN Boot ROM [Disabled]
This item appears only when you enable the previous item(s).
[Disabled] Disables Realtek LAN Boot ROM.
[Enabled] Enables Realtek LAN Boot ROM.
Onboard 1394 Controller [Enabled]
[Enabled] Enables the onboard 1394 Controller.
[Disabled] Disables the controller.
J-Micron eSATA/PATA Controller [IDE]
[Disabled] Disables the J-Micron controller.
[IDE Mode] Set to [IDE Mode] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
[AHCI Mode] Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advabced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
ASUS P7P55D
BIOS SETUP UTILITY
Advanced
[Enabled]
[HD Audio]
[Enabled]
[Disabled]
[Enabled]
[3F8/IRQ4]
Options
Enabled
Disabled
3-23
