Asus P7P55D - Motherboard - ATX User Manual page 12

P7P55D specifications summary
ASUS Unique Features
ASUS Exclusive
Overclocking Features
Back Panel I/O Ports
xii
ASUS Hybrid Processor – ASUS TurboV EVO
- Auto Tuning, TurboV, and Turbo Key
ASUS Hybrid Phase
- T.Probe Technology for Active Cooling
- 12+2 Phase Power Design
ASUS Hybrid OS – Express Gate
ASUS Xtreme Design
ASUS Exclusive Features
- MemOK!
- ASUS EPU
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Stylish Heat-sink solution
- ASUS Fanless Design: Stack Cool 3
- ASUS Fan Xpert
ASUS Crystal Sound
- ASUS Noise Filter
ASUS EZ DIY:
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS My Logo 2
- Multi-language BIOS
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.00625V increment
- vIMC: 49-step IMC voltage control
- vDRAM Bus: 81-step DRAM voltage control
- vPCH: 2-step chipset voltage control
- vCPU PLL: 4-step reference voltage control
SFS (Stepless Frequency Selection):
- Internal Base Clock tuning from 80MHz up to 500 MHz at
1MHz increment
- PCI Express frequency tuning from 100MHz up to 200MHz
at 1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
1 x PS/2 Keyboard port (Purple)
1 x PS/2 Mouse port (Green)
1 x Optical S/PDIF Out
1 x IEEE1394a
1 x eSATA 3.0 Gb/s port (SATA on-the-go)
1 x RJ45 port
8 x USB 2.0/1.1
8-channel Audio I/O
(continued on the next page)
