VGA configuration
Single VGA/PCIe card
Dual VGA/PCIe card
• In single VGA card mode, use the PCIe 2.0 x16_1 slot (blue) for a PCI Express x16
graphics card to get better performance.
• We recommend that you provide sufficient power when running CrossFireX™ mode.
See page 2-38 for details.
• Connect a chassis fan to the motherboard connector labeled CHA_FAN1/2 when
using multiple graphics cards for better thermal environment. See page 2-37 for
details.
ASUS P7P55D
PCI Express operating mode
PCIe x16_1
x16 (Recommend for
single VGA)
x16
PCIe x16_2
x4 (PCIe card)
x4
2-23
