Active Processor Cores [All]
[All]
[1]
[2]
A20M [Disabled]
[Enabled]
[Disabled]
Intel(R) SpeedStep (TM) Tech [Enabled]
[Enabled]
[Disabled]
Intel(R) TurboMode tech [Enabled]
[Enabled]
[Disabled]
Intel(R) C-STATE Tech [Disabled]
[Enabled]
[Disabled]
C State package limit setting [Auto]
This item appears only when you set the Intel(R) C-STATE Tech item to [Enabled]. We
recommend that you set this item to [Auto] for BIOS to automatically detect the C-State mode
supported by your CPU. Configuration options: [Auto] [C1] [C3] [C6] [C7]
3.6.2
North Bridge Configuration
The North Bridge menu allows you to change the advanced chipset settings.
North Bridge Chipset Configuration
IMC Type : Havendale
Memory Remap Feature
PCI MMIO Allocation: 4GB To 3072MB
Memory Remap Feature [Enabled]
[Disabled] Do not allow remapping of memory.
[Enabled]
3-22
Activate all CPU cores in the processor package.
Activate only 1 CPU core in the processor package.
Activate 2 CPU cores in the processor package.
Legacy OSes and APs may need this function enabled.
Disables this function.
The CPU speed is controlled by the operating system.
The CPU runs at its default speed.
Allows processor cores to run faster than marked frequency in specific
condition.
Disables this function.
Allows the CPU to save more power under idle mode. Enable this item only
when you install a C-State Technology-supported CPU.
Disables this function.
BIOS SETUP UTILITY
Advanced
[Enabled]
Allows for the segment of system memory that was previously overwritten
by PCI devices to be remapped above the total physical memory.
ENABLE: Allow
remapping of
overlapped PCI memory
above the total
physical memory.
DISABLE: Do not allow
remapping of memory.
Chapter 3: BIOS setup
