xStack® DGS-3120 Series Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
TFTP Server IP
Destination File
Source File
Filter
Click Upload to initiate the upload.

Upload Configuration To HTTP

This page allows the user to upload the configuration file from the Switch to a computer.
The fields that can be configured are described below:
Parameter
Unit
Source File
Click Upload to initiate the upload.
Figure 12–14 Upload Configuration – TFTP window (EI Mode Only)
Description
Use the drop-down menu to select a unit for uploading the configuration file.
Enter the TFTP server IP address used.
IPv4 Click the radio button to enter the TFTP server IP address used.
IPv6 (EI Mode Click the radio button to enter the TFTP server IPv6 address
Only)
used.
Enter the location and name of the Destination File.
Enter the location and name of the Source File.
Use the drop-down menu to include, begin or exclude a filter like SNMP, VLAN or STP.
Select the appropriate Filter action and enter the service name in the space provided.
Figure 12–15 Upload Configuration – HTTP window
Description
Use the drop-down menu to select a unit for uploading the configuration file.
Enter the location and name of the Source File.
309
