ProSafe 20-AP Wireless Controller WC7520 Reference Manual
Table 43. Controller Summary Screen Information (Continued)
Setting
WPA2
Rogue Access Points
Rogue AP current
Rogue AP count 24hrs
Network Info
This information is self-explanatory.

Viewing Wireless Controller Usage

Figure 93.
The Controller Usage screen displays a graphic of the average data traffic rate that was
received and transmitted over the last 24 hours by all access points that are managed by the
wireless controller and by the rogue access points that were detected by the wireless
controller. Select the type of usage you want to display by clicking on one of the following
tabs:
• 2.4 GHz Band Usage. Displays combined 802.11b-, 802.11bg-, and 802.11ng-mode
usage (shown in
Description
The number of wireless clients that are connected to managed access points using
security profiles configured with WPA2.
The total number of unique rogue and unmanaged neighboring access points that
are detected now by the wireless controller.
The total number of unique rogue and unmanaged neighboring access points that
were detected over the last 24 hours by the wireless controller.
Figure 93).
