JUNOSe 11.1.x Policy Management Configuration Guide

Figure 15: Arbitrary Interface Groups Configuration

1.
2.
148
Example: Arbitrary Interface Groups Hierarchical Policy Configuration
VOICE_RATE, Committed Rate: 64 Kbps
Peak Rate: 0 Mbps
Committed Action: transmit unconditional
Conformed Action: drop
Exceeded Action: drop
At I2 and I4:
No policer configured
I1 and I2 feed into a single policer with the following configuration: AGG,
Committed Rate: 1 Mbps, Peak Rate: 0 Mbps, Committed Action: transmit,
Conformed Action: drop, Exceeded Action: drop
Create an aggregate rate limit that can be shared across multiple interfaces.
Create an external parent group to hold this rate limit.
host1(config)#rate-limit-profile AGG two-rate hierarchical
host1(config-rate-limit-profile)#committed-rate 1000000
host1(config-rate-limit-profile)#committed-action transmit final
host1(config-rate-limit-profile)#exit
host1(config)#parent-group EPG1
host1(config-parent-group)#rate-limit-profile AGG
host1(config-parent-group)#exit
Create a policy list to be attached to all voice sessions.
