FPGA Hardware Classifiers
Classification is the process of taking a single data stream in and sorting it into
multiple output substreams. The classifier engine on an E Series router is a
combination of PowerPC processors, working with an FPGA for a hardware assist.
In the Differentiated Services (DiffServ) architecture, two basic types of classifiers
exist. The first classifier type is a multifield (MF) classifier. The MF classifier can
examine multiple fields in the IP datagram header to determine the service class to
which a packet belongs.
Interface Type Hardware Classifier
VLAN Not supported
Interface Type Hardware Classifier
All interface types –
Frame Relay Not supported
GRE tunnels Not supported
IP Destination address
Destination port
ICMP type and code
IGMP type
Protocol
Source address
Source port
IPv6 Destination address
Destination port
ICMPv6 type and
code
Protocol
Source address
Source port
MPLS Not supported
VLAN Not supported
Chapter 8: Policy Resources
Software Classifier
User priority
Software Classifier
Color
Traffic class
User packet class
DE bit
ToS
Destination route
class
IP flags
IP fragmentation
Local
Source route class
TCP flags
ToS
Destination route
class
Local
Source route class
TC field
TCP flags
EXP
User priority
