JUNOSe 11.1.x Policy Management Configuration Guide
forward
host1#show policy-list mpl_88000001
IP Policy mpl_88000001
Administrative state: enable
Reference count:
forward
forward
forward
forward
forward
Overlapping Classification for IP Input Policy
IP auxiliary input policy can be used with IP input policy to provide overlapping
classification. Two policies, each with a set of independent rules and actions, run in
sequence so that each policy can independently produce a set of actions in sequence.
A packet that matches both the input policies and auxiliary input policies is subject
to both sets of policy actions.
E Series routers allow four input and two output policies per IP interface:
122
Overlapping Classification for IP Input Policy
Classifier control list: D, precedence 100, external parent-group EPG2 parameter
abcd
Parent group: X, parent-group Y
rate-limit-profile R3
Parent group: Y
rate-limit-profile R4
1
Classifier control list: *, precedence 100, parent-group Z
Classifier control list: A, precedence 100, parent-group X
Classifier control list: B, precedence 100, parent-group X_1
Classifier control list: C, precedence 100, parent-group Y
Classifier control list: D, precedence 100, external parent-group EPG2 parameter
abcd
Parent group: X, parent-group Z
rate-limit-profile R1
Parent group: Z
rate-limit-profile R2
Parent group: X_1, parent-group P2_Y
rate-limit-profile R3
Parent group: Y
rate-limit-profile R4
Referenced by interfaces:
ATM5/0.1
input policy, statistics enabled, virtual-router default
Referenced by profiles:
None
Component policies:
P1
P2
One secure input policy
Three nonsecure input policies
One secure output policy
One nonsecure output policy
Policy Table
------ -----
