Do not use J2 jumpers on J6. The internal contacts
will be bent and cannot be reused on J2 without
them falling off.
T
SCSI ID=0, no jumpers
T
SCSI ID=1, pins 1-2 jumpered
T
SCSI ID=2, pins 3-4 jumpered
T
SCSI ID=3, pins 1-2 and 3-4 jumpered
T
SCSI ID=4, pins 5-6 jumpered
T
SCSI ID=5, pins 1-2 and 5-6 jumpered
T
SCSI ID=6, pins 3-4 and 5-6 jumpered
T
SCSI ID=7, pins 1-2, 3-4, and 5-6 jumpered
T
SCSI ID=8, pins 7-8 jumpered
T
SCSI ID=9, pins 1-2 and 7-8 jumpered
T
SCSI ID=10, pins 3-4 and 7-8 jumpered
T
SCSI ID=11, pins 1-2, 3-4, and 7-8 jumpered
T
SCSI ID=12, pins 5-6 and 7-8 jumpered
T
SCSI ID=13, pins 1-2, 5-6, and 7-8 jumpered
T
SCSI ID=14, pins 3-4, 5-6, and 7-8 jumpered
T
SCSI ID=15, pins 1-2, 3-4, 5-6, and 7-8 jumpered
CAUTION
Setting Jumpers 6-11
