Specifications
Power consumption
Noise (Operation)
Ideal operating environment 15 °C to 30 °C (59 ~ 86 °F), 10% to 80% RH with no condensation
Operating Environment
Dimensions (w x d x h)
Printer only
Printer + Stand
Weight (including printhead, ink tanks)
Printer only
Printer + Stand
*1. If using a USB 2.0 interface in Hi-Speed mode, the following environment is required.
• Computer: USB 2.0 Hi-Speed-compatible
• OS: Windows Server 2003/Windows XP/Windows 2000/Mac OS X v10.3.3 or later
• USB2.0 driver: Microsoft USB 2.0 driver (The Microsoft USB 2.0 driver can be obtained using Windows Update, or
from the Service Pack.)
• USB cable: USB 2.0-authorized cable
• USB 2.0 interfaces whose operations have been approved by Cannon (i.e., Microsoft OS standard USB drivers):
• Adaptec USB 2.0 expansion card: USB2CONNECT3100
• Adaptec USB 2.0 expansion card: USB2CONNECT5100
• Adaptec USB 2.0 expansion card: USB2CONNECT2000LP
• Intel: 845G chip set
• Sis: SiS740 chip set
For problems concerning the chip sets described above, consult the relevant computer manufacturer.
*2. Either a network interface port or an IEEE1394 board can be mounted. Printers sold in the U.S.A. are shipped with
the Network board installed as a standard item (not an option).
*3. Either a photo black ink or matte black ink can be mounted.
*4. If printing to Newsprint for Proof, use the RIP software (sold separately).
*5. Borderless Size and Oversize may not be able to be printed, depending on the media type and size. Further,
depending on the paper type, Borderless Size may be at the left and right edges only.
*6. If oversize has been selected, set media 10 mm min. wider than the media size selected, and set the roll height 10
mm min. higher than the roll media, or 28 mm min. higher than the cut sheet.
*7. If an option board has been mounted, this may be different.
*8. A considerable amount of power is consumed even when the power supply has been turned OFF. To completely
eliminate power consumption, remove the power supply plug from the outlet.
• These specifications are subject to change for improvements.
• The above specifications may vary for different operating environments.
1- 57
*7
Max. 160 W (same as using Network Interface Board)
Sleep Mode: 100-115V: Less than 6W (same as using Network Interface Board)
220-240V: Less than 9W
*8
Power off : Less than 1 W
Approximately 54 dB (A) or less (less than 6.9 Bels)
5 °C to 35 °C (41 ~ 95 °F), 10% to 90% RH with no condensation
1642 mm x 715 mm x 478 mm
1642 mm x 972 mm x 1075 mm
Approx. 80 kg
Approx. 98 kg
