Printing with Cut Sheets
Important
Align and load parallel the cut sheets to the paper
alignment line on the right of the platen. If the paper is
loaded at an angle, an error will occur. If this happens,
reload the paper straight.
Note
If the release lever is open, the platen paper suction
can be adjusted. If it is difficult to load the paper, adjust
the suction using the [
button (weaker) on the operation panel.
This printer uses vacuum to hold paper against holes
in the platen. A warning may sound depending on the
paper position, but this is not abnormal.
If the buzzer sounds, align the paper with the guide
and try changing the position 1 mm to the left or right.
The suction time when the media is loaded is approx.
30 seconds. If the media cannot be loaded during
suction, remove and then reinsert the paper. Suction
will be performed again.
3
Lower the release lever, and close the top
cover.
Media Type is displayed.
2- 40
] button (stronger) and [ ]
4
Press [ ] or [ ] to select the name of the
media type then press the OK button.
If the same type of media already matches the
loaded media, just press the OK button.
Media Type
HW Coated
An equals (=) mark is displayed to the left of the
option to show the media type that has been
selected, and the printer begins preparing to feed
the cut sheets.
The paper size and angle will be detected, and
printing will be enabled if there are no problems.
